M73 Body With Lsa Connector Box (white)
ITCurry #: N5993187 | Article #: MX-M73A-LSA-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
M73A IP camera module (body) for connecting up to three additional functional and optical sensor modules (to be ordered individually) • ONVIF-compliant MOBOTIX 7 system platform (Profile S, T) with H.264 (Triple Streaming), H.265, MxPEG+ and M-JPEG • Max. image size (per image sensor): 4K UHD (3840 x 2160 pixels), 16:9 • WDR: up to 120 dB • Functional extensions (via optional MOBOTIX modules): Audio (Microphone & Speaker), MultiSense (PIR, temperature, brightness sensor, Microphone), IR Light (supports 15°, 45°, 95° lenses), 1x miniUSB • Operating conditions: IP66/IK07, -40 to 65°C (-40 to 149 °F) • Internal DVR: 8 GB microSD (for MxPEG+ recordings) • Max. Power consumption: 25 W, supply via network cable, PoE Class 4 (IEEE 802.3af/at) • Connections: 1x LSA terminal for weatherproof network connection via laying cable (Ethernet 1000BaseT), 3x MOBOTIX module connection (optical/functional), I/0 (1x input, 1x output), 1x line in,1x line out, 1x miniUSB • Software interface for MOBOTIX Certified Apps (based on Deep Learning, approx. 20 different 30-day demo versions pre-installed) • • Housing: Aluminium, PBT-30GF • Color: white
| Features | |
| Type | Housing |
| Placement supported | Universal |
| Product colour | White |
| International Protection (IP) code | IP66 |
| Certification | EN55032 EN55035 EN50121-4 EN61000-6-1 EN61000-6-2 EN61000-6-3 EN61000-6-4 AS/ NZS CISPR32 CFR47 FCC part15B EN62368 NRTL |
| Image sensor | |
| Megapixel (approx.) | 4 MP |
| Resolution | 3840 x 2160 pixels |
| Ports & interfaces | |
| Number of outputs | 1 outputs |
| Number of inputs | 1 inputs |
| Ethernet LAN | Y |
| Wi-Fi | Y |
| Power | |
| Rated power | 25 W |
| Weight & dimensions | |
| Width | 153 mm |
| Depth | 232 mm |
| Height | 228 mm |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 65 øC |
| Logistics data | |
| Harmonized System (HS) code | 85299020 |
| Warranty | |
| Base Warranty | Non Non |
