ThinkSystem SR650 V2 - Gold 5315Y - 64GB Ram - 9350-8i - 8x 2.5in SAS Open bay - 3-(x16,-x8, x8)-Gen4 - 750W Titanium
ITCurry #: M852TN17 | Article #: 7Z73A08TEA-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
The Lenovo ThinkSystem SR650 V2 is an ideal 2-socket 2U rack server for small businesses up to large enterprises that need industry-leading reliability, management, and security, as well as maximizing performance and flexibility for future growth. The SR650 V2 is designed to handle a wide range of workloads, such as databases, virtualization and cloud computing, virtual desktop infrastructure (VDI), infrastructure security, systems management, enterprise applications, collaboration/email, streaming media, web, and HPC.
This product guide provides essential pre-sales information to understand the ThinkSystem SR650 V2 server, its key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the SR650 V2 and consider its use in IT solutions.
| Processor | |
| Processor manufacturer | Intel |
| Processor family | Intel© Xeon© Gold |
| Processor generation | 3rd Generation Intel© Xeon© Scalable |
| Processor model | 5315Y |
| Processor frequency | 3.2 GHz |
| Processor boost frequency | 3.6 GHz |
| Processor cores | 8 |
| Processor cache | 12 MB |
| Motherboard chipset | Intel C621A |
| Number of processors installed | 1 |
| Memory | |
| Internal memory | 64 GB |
| Internal memory type | DDR4-SDRAM |
| Memory slots | 32x DIMM |
| ECC | Yes |
| Memory layout (slots x size) | 1 x 64 GB |
| Maximum internal memory | 12 TB |
| Storage | |
| RAID support | Yes |
| Hot-swap | Yes |
| Optical drive type | No |
| Internal drive bays | 8 |
| Network | |
| Ethernet LAN | Yes |
| Design | |
| Chassis type | Rack (2U) |
| Product colour | Black, Silver |
| Cooling type | Active |
| Rack mounting | Yes |
| Performance | |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Software | |
| Compatible operating systems | Microsoft Windows Server Red Hat Enterprise Linux SUSE Linux Enterprise Server VMware ESXi |
| Power | |
| Power supply | 750 W |
| Operational conditions | |
| Storage temperature (T-T) | -40 - 60 øC |
| Storage relative humidity (H-H) | 8 - 90% |
| Operating altitude | 0 - 3050 m |
| Weight & dimensions | |
| Width | 445 mm |
| Depth | 764 mm |
| Height | 87 mm |
| Weight | 38.8 kg |
| Warranty | |
| Base Warranty | Non Non |
