Product Information
Rapid Data Growth
The enterprise data storage marketplace is changing at a rapid pace and organizations of all sizes are experiencing IT operational challenges. Businesses now need greater data collaboration, agility and cost efficiency to stay ahead of the competition. The right infrastructure allows clients to share information, secure transactions and drive real-time insights.
Storage | |
Storage drives installed | No |
Installed storage drive type | No |
Supported storage drive types | HDD & SSD |
Number of storage drives supported | 24 |
Storage drive interface | Serial Attached SCSI (SAS) |
Storage drive size | 2.5" |
RAID levels | 0, 1, 5, 6, 10 |
Ports & interfaces | |
USB connectivity | No |
Host ports | 4 |
SAS host port | Yes |
Number of SAS host ports | 4 |
Design | |
Chassis type | Rack (2U) |
Product colour | Black, Silver |
LED indicators | Yes |
Redundant fans support | Yes |
Performance | |
Device class | Large Enterprise Business |
Power | |
Power supply unit (PSU) capacity | 800 W |
Number of power supply units | 2 |
Redundant power supply (RPS) support | Yes |
Power consumption (typical) | 233 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Weight & dimensions | |
Width | 483 mm |
Depth | 556 mm |
Height | 87 mm |
Weight | 26.7 kg |
Logistics data | |
Harmonized System (HS) code | 84717020 |
Operational conditions | |
Operating temperature (T-T) | 10 - 35 øC |
Operating relative humidity (H-H) | 20 - 80% |
Storage temperature (T-T) | -10 - 50 øC |
Storage relative humidity (H-H) | 8 - 80% |
Operating altitude | 0 - 3050 m |
Warranty | |
Base Warranty | Non Non |
