Kingston’s Industrial SD card delivers superior endurance and reliability across industrial applications including automation, telecommunication, data systems, building management and POS systems. It is designed and tested to withstand the most demanding environmental factors. With an operating temperature of -40°C to 85°C, Kingston’s Industrial SD card can operate normally in extended temperature ranges. The card utilises the industry-leading pSLC mode to provide reliable read speeds of up to 100MB/s*. It is rated up to 1920 TBW** with 30K P/E cycles and has a built-in feature set specific to endurance, performance and industrial needs. Kingston’s Industrial SD is available in capacities from 8GB–64GB***.
Durable in extreme temperatures
Designed and tested to withstand an extended temperature range of -40°C to 85°C for use in harsh conditions.
High endurance and reliability
Up to 1920 TBW** and rated to endure 30K P/E cycles to meet requirements for a wide range of industrial applications.
UHS-I compliant
Speeds of up to 100MB/s* with U3, V30 and A1 support for Android-based applications
Industrial-grade built-in features
Wear levelling, bad block management and an optional health monitoring tool to manage the lifespan of your card****.
Memory | |
Capacity | 32 GB |
Flash card type | SDHC |
Read speed | 100 MB/s |
Write speed | 80 MB/s |
Internal memory type | UHS-I |
UHS Speed Class | Class 3 (U3) |
Video Speed Class | V30 |
Application performance class | A1 |
Flash memory class | Class 10 |
Supported file systems | FAT32 |
Features | |
Product colour | Black |
Protection features | Temperature proof, Waterproof, X-ray proof |
Power | |
Memory voltage | 3.3 V |
Operational conditions | |
Operating temperature (T-T) | -40 - 85 øC |
Storage temperature (T-T) | -40 - 85 øC |
Weight & dimensions | |
Width | 31.8 mm |
Depth | 23.9 mm |
Height | 2 mm |
Weight | 2.31 g |
Packaging data | |
Quantity per pack | 1 pc(s) |
Package width | 101.6 mm |
Package depth | 5.6 mm |
Package height | 114.3 mm |
Package weight | 13.83 g |
Logistics data | |
Country of origin | China, Taiwan |
Master (outer) case width | 114.3 mm |
Master (outer) case length | 120.7 mm |
Master (outer) case height | 94 mm |
Master (outer) case gross weight | 396.02 g |
Products per master (outer) case | 25 pc(s) |
Warranty | |
Base Warranty | Non Non |
