96GB Ddr5 5600mt/s ECC Reg Cl46 DIMM 2rx4 Micron B Renesas
ITCurry #: 2935H431 | Article #: KSM56R46BD4PMI-96MBIFlash Sale
Less than 5 units remaining
Less than 10 units remaining
Less than 20 units remaining
More than 20 units are available
{{new Date(new Date(parseInt((dataContainer.PromoDetail.EndDate).split('(')[1].split(')')[0])) - new Date()).getDate()}} days remaining
{{new Date(new Date(parseInt((dataContainer.PromoDetail.EndDate).split('(')[1].split(')')[0])) - new Date()).getDate()}} day remaining
Price:
502.75
Inc VAT
Ex VAT
Shipping:
Out of Stock. Contact Us!
Key Specifications
-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Inc VAT
Ex VAT
Out of Stock. Contact Us!
Inc VAT
Ex VAT
Out of Stock. Contact Us!
Related products
Product Information
Kingston's KSM56R46BD4PMI-96MBI is a 12G x 80-bit (96GB) DDR5-5600 CL46 SDRAM (Synchronous DRAM), 2Rx4, ECC, memory module, based on forty 6G x 4-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR5-5600 timing of 46-45-45 at 1.1V. Each 288-pin DIMM uses gold contact fingers.
| Warranty | |
| Base Warranty | Non Non |
| Features | |
| Buffered memory type | Registered (buffered) |
| On-Die ECC | Yes |
| CAS latency | 46 |
| Internal memory | 96 GB |
| Memory layout (modules x size) | 1 x 96 GB |
| Internal memory type | DDR5 |
| Memory clock speed | 2800 MHz |
| Memory data transfer rate | 5600 MT/s |
| Component for | PC/Server |
| Memory form factor | 288-pin DIMM |
| ECC | Yes |
| Memory ranking | 2 |
| Memory voltage | 1.1 V |
| Module configuration | 12288M x 80 |
| Row cycle time | 48 ns |
| Refresh row cycle time | 295 ns |
| Row active time | 32 ns |
| SPD profile | Yes |
| Programming power voltage (VPP) | 1.8 V |
| Lead plating | Gold |
| Backlight | No |
| JEDEC standard | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 95 øC |
| Storage temperature (T-T) | -55 - 100 øC |
| Technical details | |
| Compliance certificates | RoHS |
| Sustainability | |
| Sustainability compliance | Yes |
| Doesn't contain | Halogen |
| Weight & dimensions | |
| Width | 133.3 mm |
| Height | 31.2 mm |
