4GB 3200MHz Ddr4 Non-ECC Cl22
ITCurry #: 2935F803 | Article #: KVR32N22S6/4
slide 1 of 1
Price:
16.39
Ex VAT
Shipping:
FREE Shipping on orders over 100€ Ex VAT.
Out of Stock. Contact Us!
Related products
slide 7 to 11 of 14
Product Information
ValueRAM's KVR32N22S6/4 is a 512M x 64-bit (4GB) DDR4-3200 CL22 SDRAM (Synchronous DRAM), 1Rx16, memory module, based on four 512M x 16-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR4-3200 timing of 22-22-22 at 1.2V. Each 288-pin DIMM uses gold contact fingers.
| Features | |
| Buffered memory type | Unregistered (unbuffered) |
| CAS latency | 22 |
| Internal memory | 4 GB |
| Memory layout (modules x size) | 1 x 4 GB |
| Internal memory type | DDR4 |
| Memory data transfer rate | 3200 MT/s |
| Component for | PC/Server |
| Memory form factor | 288-pin DIMM |
| ECC | No |
| Memory ranking | 1 |
| Memory voltage | 1.2 V |
| Module configuration | 512M x 64 |
| Row cycle time | 45.75 ns |
| Refresh row cycle time | 350 ns |
| Row active time | 32 ns |
| Programming power voltage (VPP) | 2.5 V |
| Country of origin | Taiwan |
| Lead plating | Gold |
| JEDEC standard | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 85 øC |
| Storage temperature (T-T) | -55 - 100 øC |
| Technical details | |
| Compliance certificates | RoHS |
| Sustainability | |
| Doesn't contain | Halogen |
| Weight & dimensions | |
| Width | 133.3 mm |
| Height | 31.2 mm |
| Logistics data | |
| Harmonized System (HS) code | 84733020 |
| Warranty | |
| Base Warranty | Non Non |
