SSD P4800x Series 1.5TB 2.5in Pci-e 4.0 20nm 3dx Point Generic 10 Pack
ITCurry #: 2730C326 | Article #: SSDPE21K015TA10-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Enhanced Power Loss Data Protection
Enhanced Power Loss Data Protection prepares the SSD for unexpected system power loss by minimizing data in transition in temporary buffers, and uses on-board power-loss protection capacitance to provide enough energy for the SSD firmware to move data from the transfer buffer and other temporary buffers to the NAND, thus protecting system and user data.
Hardware Encryption
Hardware encryption is data encryption done at the drive level. This is used to ensure that the data stored on the drive is secured from unwanted intrusion.
High Endurance Technology (HET)
High Endurance Technology (HET) in SSD's combines Intel® NAND Flash Memory silicon enhancements and SSD system management techniques to help extend the endurance of the SSD. Endurance is defined as the amount of data that can be written to an SSD during its lifetime.
Temperature Monitoring and Logging
Temperature Monitoring and Logging uses an internal temperature sensor to monitor and log airflow and device internal temperature. The logged results can be accessed using the SMART command.
End-to-End Data Protection
End-to-End Data Protection ensures integrity of stored data from the computer to the SSD and back.
| Features | |
| Security algorithms | 256-bit AES |
| SSD form factor | 2.5" |
| SSD capacity | 1.5 TB |
| Interface | U.2 |
| Memory type | 3D XPoint |
| NVMe | Yes |
| Component for | Server/workstation |
| Hardware encryption | Yes |
| Read speed | 2500 MB/s |
| Write speed | 2200 MB/s |
| Random read (100% span) | 550000 IOPS |
| Random write (100% span) | 550000 IOPS |
| Read latency | 10 æs |
| Write latency | 10 æs |
| End-to-End Data Protection | Yes |
| Enhanced Power Loss Data Protection technology | Yes |
| SSD temperature monitoring | Yes |
| Temperature monitoring and logging | Yes |
| Uncorrectable Bit Error Rate (UBER) | < 1 per 10^17 bits read |
| Mean time between failures (MTBF) | 2000000 h |
| Market segment | Server |
| SSD ARK ID | 97155 |
| Power | |
| Power consumption (read) | 18 W |
| Power consumption (write) | 18 W |
| Power consumption (idle) | 7 W |
| Brand-specific features | |
| Intel High Endurance Technology (HET) | Yes |
| Intel© Rapid Start Technology | No |
| Intel© Remote Secure Erase | No |
| Intel© Smart Response Technology | No |
| Intel Smart Response Technology version | 0.00 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 70 øC |
| Maximum operating temperature | 70 øC |
| Operating vibration | 2.17 G |
| Non-operating vibration | 3.13 G |
| Operating shock | 1000 G |
| Non-operating shock | 1000 G |
| Operating / non-operating shock | 1000 G/0.5 msec |
| Warranty | |
| Base Warranty | Non Non |
| Logistics data | |
| Harmonized System (HS) code | 84717070 |
| Other features | |
| Power consumption (active) | 18 W |
| Drive capacity | 1.5 TB |
| Launch date | Q3'18 |
| Product brief URL | https://www.intel.com/content/www/us/en/solid-state-drives/optane-ssd-dc-p4800x-brief.html |
| SSD endurance rating | 164 PBW |
| SSD hardware encryption | AES 256 bit |
| SSD power consumption (active) | 18 |
| SSD power consumption (idle) | 7 |
| SSD shock | 1000 G/0.5 msec |
| Sequential reading | 2500 MB/s |
| Sequential writing speed | 2200 MB/s |
| Status | Launched |
| Last change | 63903513 |
| Intel Rapid Start Technology version | 0.00 |
| Remote Secure Erase (RSE) technology version | 0.00 |
| Product family | Data center SSD |
| Product series | Intel© OptaneT SSD DC P4800X Series |
| Product codename | Cold Stream |
