SSD Dc S4610 Series 7.6TB 2.5in Pci-e 3.1 X4 3d2 Tlc Single Pack
ITCurry #: 2730A918 | Article #: SSDPE2KE076T801-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Enhanced Power Loss Data Protection
Enhanced Power Loss Data Protection prepares the SSD for unexpected system power loss by minimizing data in transition in temporary buffers, and uses on-board power-loss protection capacitance to provide enough energy for the SSD firmware to move data from the transfer buffer and other temporary buffers to the NAND, thus protecting system and user data.
Hardware Encryption
Hardware encryption is data encryption done at the drive level. This is used to ensure that the data stored on the drive is secured from unwanted intrusion.
High Endurance Technology (HET)
High Endurance Technology (HET) in SSD's combines Intel® NAND Flash Memory silicon enhancements and SSD system management techniques to help extend the endurance of the SSD. Endurance is defined as the amount of data that can be written to an SSD during its lifetime.
Temperature Monitoring and Logging
Temperature Monitoring and Logging uses an internal temperature sensor to monitor and log airflow and device internal temperature. The logged results can be accessed using the SMART command.
End-to-End Data Protection
End-to-End Data Protection ensures integrity of stored data from the computer to the SSD and back.
| Features | |
| Security algorithms | 256-bit AES |
| SSD form factor | U.2 |
| SSD capacity | 7.68 TB |
| Interface | PCI Express 3.1 |
| Memory type | TLC 3D NAND |
| NVMe | Yes |
| Component for | Server/workstation |
| Hardware encryption | Yes |
| Read speed | 3200 MB/s |
| Write speed | 3200 MB/s |
| Random read (4KB) | 651000 IOPS |
| Random write (4KB) | 219000 IOPS |
| Random read (100% span) | 651000 IOPS |
| Random write (100% span) | 219000 IOPS |
| Random latency - read (up to) | 95 æs |
| Random latency - write (up to) | 20 æs |
| Sequential latency - read (up to) | 12 æs |
| Sequential latency - write (up to) | 18 æs |
| Read latency | 77 æs |
| Write latency | 18 æs |
| End-to-End Data Protection | Yes |
| Enhanced Power Loss Data Protection technology | Yes |
| SSD temperature monitoring | Yes |
| Temperature monitoring and logging | Yes |
| Uncorrectable Bit Error Rate (UBER) | < 1 per 10^17 bits read |
| Mean time between failures (MTBF) | 2000000 h |
| Market segment | Server |
| SSD ARK ID | 140107 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | G162706 |
| Power | |
| Power consumption (read) | 15 W |
| Power consumption (write) | 15 W |
| Power consumption (idle) | 5 W |
| Brand-specific features | |
| Intel High Endurance Technology (HET) | Yes |
| Intel© Rapid Start Technology | No |
| Intel© Remote Secure Erase | No |
| Intel© Smart Response Technology | No |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 55 øC |
| Maximum operating temperature | 55 øC |
| Operating vibration | 2.17 G |
| Non-operating vibration | 3.13 G |
| Operating shock | 1000 G |
| Non-operating shock | 100 G |
| Operating / non-operating shock | 1000G (0.5ms) |
| Weight & dimensions | |
| Width | 15 mm |
| Weight | 139 g |
| Logistics data | |
| Harmonized System (HS) code | 84717070 |
| Other features | |
| Power consumption (active) | 15 W |
| Drive capacity | 7.68 TB |
| Launch date | Q2'18 |
| SSD endurance rating | 44.25PBW |
| SSD hardware encryption | AES 256 bit |
| SSD power consumption (active) | 15W |
| SSD power consumption (idle) | 5W |
| SSD shock | 1000G (0.5ms) |
| SSD weight | 139 g |
| Sequential reading | 3200 MB/s |
| Sequential writing speed | 3200 MB/s |
| Status | Launched |
| Last change | 63903513 |
| Product family | Data center SSD |
| Product series | Intel© SSD DC P4610 Series |
| Product codename | Cliffdale Refresh |
| Warranty | |
| Base Warranty | Non Non |
