Product Information
A 12-Gb eight internal port SAS 3.0 mezzanine card with I/O Controller (IOC), advanced management, RAID 0,1 and hybrid RAID 5, JBOD and PCIe Generation 3.
| Ports & interfaces | |
| Supported storage drive interfaces | SAS, Serial ATA |
| Host interface | PCI Express x8 |
| PCI Express slots version | 3.0 |
| Internal SAS ports | 8 |
| Performance | |
| RAID levels | 0, 1, 10, 5, 50 |
| Data transfer rate | 12 Gbit/s |
| Form factor | Storage Connector Module |
| Connector orientation | Side |
| JBOD function | Yes |
| Number of devices supported | 128 |
| Sustained data transfer rate (native) | 12288 MB/s |
| Export Control Classification Number (ECCN) | 4A994B |
| Commodity Classification Automated Tracking System (CCATS) | NA |
| Compatible products | Intel Server System R1208WT2GS Intel Server System R1208WTTGS Intel Server System R1304WT2GS Intel Server System R1304WTTGS Intel Server System R2208WT2YS Intel Server System R2208WTTYC1 Intel Server System R2208WTTYS Intel Server System R2224WTTYS Intel Server System R2308WTTYS Intel Server System R2312WTTYS |
| Processor | |
| Built-in processor | SAS3008 |
| Processor family | LSI |
| Processor model | LSISAS3008 |
| Technical details | |
| Born on date | Q3'14 |
| Data transfer rate | 12288 Mbit/s |
| Launch date | Q3'14 |
| PCI Express host interface | PCIe x8 Gen3 |
| Product name | Intel Integrated RAID Module RMS3HC080 |
| Product type | RAID |
| RAID connector orientation | Side |
| RAID keying | SIOM |
| Status | Launched |
| Last change | 63903513 |
| Expected discontinuance date | Q2'23 |
| Extended warranty available for purchase (select countries) | Yes |
| Last order date | 2019-08-03 05:00:37 |
| Target market | Entry |
| Warranty | |
| Base Warranty | Non Non |
| System requirements | |
| Windows operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Compatible operating systems | Windows, Linux, VMware |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 65 øC |
| Weight & dimensions | |
| Packaging content | (1) Intel Integrated RAID Module RMS3HC080, (4) standoffs, and (4) standoff locking pins |
| Logistics data | |
| Harmonized System (HS) code | 84733080 |
| Other features | |
| PCI Card form factor | Full-height (low-profile) |
| Intel long life | Yes |
| Internal ports | 8 |
| Supported devices | SAS/SATA |
| Market segment | Server |
| RAID ARK ID | 81863 |
