Synergy 4-port Frame Link Module
ITCurry #: 1171ADD2 | Article #: 876852-B21-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Do your datacenter systems provide continuous uptime with security – while allowing for future growth? HPE Synergy Frame Link Modules provide basic management functions for HPE Synergy Frames like auto-discovery of resources and health-status monitoring to keep your systems up and running. Security is enhanced by separating the data network from the management network and by a variety of capabilities like Hardware Root of Trust, Secure Start, and Trusted Platform Module (TPM) file encryption. HPE Synergy Frame Link Modules also link multiple frames together into a management ring to scale your single management environment for future growth (up to 21 frames).
What is new supporting point:
Hardware Root of Trust prevents tampering by detecting and validating that the correct firmware is in use on the HPE 4-port Frame Link Module.
Secure Start maintains secure firmware updates and attack resilience by validating any new firmware on the HPE 4-port Frame Link Module from the previous firmware before switching the boot path.
File Encryption uses the Trusted Platform Module (TPM) on the HPE 4-port Frame Link Module for robust device security using validated encryption keys.
HPE 4-port Frame Link Modules provide flexibility for long-distance connections (up to tens of kilometers) to scattered frames and to remote subnets of a data center.
| Performance | |
| Data transfer rate | 10000 Mbit/s |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 4 |
| USB 2.0 ports quantity | 1 |
| Design | |
| Rack capacity | 2U |
| Weight & dimensions | |
| Width | 82.5 mm |
| Depth | 286.2 mm |
| Height | 20.8 mm |
| Weight | 630 g |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Warranty | |
| Base Warranty | Non Non |
