ProLiant DL145 Gen11 - 1p 8024P - 1x32GB-R - 2SFF NS204i-u NC BCM5719 - 2x1000W PS - EU
ITCurry #: 1171ANJ1 | Article #: P79814-425-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Ready to experience exceptional performance, affordability, and versatility with a modern edge computing server solution? The HPE ProLiant DL145 Gen11 server is a 2U, single processor, robust edge computing server designed to cater to the needs of retail, manufacturing, telecommunications, and various other industries. It offers a compelling alternative to traditional servers with its sleek design, affordable pricing, and quiet operation. Powered by the 4th Generation AMD EPYC™ 8004 Zen4c architecture, this server provides up to 64 energy-efficient cores, PCIe Gen5 speed, and high-performance EDSFF storage. It can operate continuously in temperatures ranging from -5°C to 55°C and withstand high-dust and high-vibration environments. It is engineered for today's hybrid world, allowing enterprises to virtualize traditional IT applications to power their businesses and accelerate AI success.
What is new supporting point:
Various mounting option — Wall, desk, and rack.
Operating temperature support up to to 55° C, bezel with air filter, designed to qualify for NEBS Level 3[1].
Support for 8 to 64 cores and TDP ratings of up to 200W.
AMD EPYC™ 8004 processor family, customized for edge computing and environments with physical constraints such as limited power, space, or cooling, 8 to 64 cores, TDP ratings of up to 200W.
Compact size, 15-inches wide, 16-inches deep (without bezel), 20-inches (with bezel).
Support for three single-wide GPUs.
| Processor | |
| Processor manufacturer | AMD |
| Processor family | AMD EPYC |
| Processor model | 8024P |
| Processor frequency | 2.4 GHz |
| Processor boost frequency | 3 GHz |
| Processor cores | 8 |
| Processor cache | 32 MB |
| Motherboard chipset | AMD SoC |
| Number of processors installed | 1 |
| Processor cache type | L3 |
| Maximum number of SMP processors | 1 |
| Memory | |
| Internal memory | 32 GB |
| Internal memory type | DDR5-SDRAM |
| Memory ranking | 2 |
| Memory slots | 6x DIMM |
| ECC | Yes |
| Memory clock speed | 4800 MHz |
| Memory layout (slots x size) | 1 x 32 GB |
| Maximum internal memory | 768 GB |
| Storage | |
| Maximum storage capacity | 7.68 TB |
| Total storage capacity | 0 GB |
| SSD interface | PCI Express 4.0 |
| NVMe | Yes |
| Supported SSD sizes | 2.5" |
| Number of SSDs supported | 2 |
| RAID support | Yes |
| RAID levels | 1 |
| Supported RAID controllers | HPE NS204i-u Gen11 NVMe Hot Plug Boot Optimized Storage Device |
| Hot-Plug support | Yes |
| Optical drive type | No |
| Graphics | |
| On-board graphics card | Yes |
| Maximum graphics card memory | 16 MB |
| Network | |
| LAN controller | Broadcom BCM5719 |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| Expansion slots | 1 x16 FHHL PCIe Gen5; 1 OCP 3.0 Slot as default |
| DisplayPorts quantity | 1 |
| Design | |
| Chassis type | Rack (2U) |
| Rack mounting | Yes |
| Redundant fans support | Yes |
| Performance | |
| Remote administration | iLO 6 ASIC |
| Management platform | HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download), HPE iLO Advanced, HPE iLO Advanced Premium Security Edition, and HPE OneView Advanced (require licenses), HPE Compute Ops Management (subscription included). Refer to the iLO 6 User Guide |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Software | |
| Operating system installed | No |
| Power | |
| Power supply type | 2x HPE ProLiant 900W-1000W Flex Slot Titanium Hot Plug Reverse Air Flow AC Power Supply Kit |
| Redundant power supply (RPS) support | Yes |
| Power supply | 1000 W |
| Number of redundant power supplies supported | 2 |
| Number of redundant power supplies installed | 2 |
| Number of main power supplies | 2 |
| Sustainability | |
| Sustainability certificates | ENERGY STAR |
| Weight & dimensions | |
| Width | 359.4 mm |
| Depth | 406.6 mm |
| Height | 87.5 mm |
| Other features | |
| Standard fans | 4x Standard Fans |
| Storage drive type | None ship standard, 2 SFF supported |
| Security features | TPM 2.0, silicon root of trust, secure boot, chassis intrusion detection and bezel lock, and Kensington lock, optional data-at-rest hardware encryption. For full security features refer to the QuickSpecs. |
| Number of processors supported | 1 |
| Warranty | |
| Base Warranty | Non Non |
