Intel Xeon 6511P 2.3GHz 16-core 150W Processor for HPE
ITCurry #: 1171APS3 | Article #: P74505-B21
slide 1 of 1
Related products
slide 7 to 11 of 14
Product Information
Intel Xeon 6 Processors
Trusted performance. Exceptional efficiency. Intel Xeon processors are optimized to deliver new levels of performance across the greatest range of workloads, while offering improved efficiency and lower power consumption.
| Processor | |
| Processor manufacturer | Intel |
| Processor base frequency | 2.3 GHz |
| Processor family | Intel© Xeon© |
| Processor cores | 16 |
| Processor socket | LGA 4710 |
| Processor threads | 32 |
| Processor operating modes | 64-bit |
| Processor boost frequency | 4.1 GHz |
| Processor cache | 72 MB |
| Processor cache type | Smart Cache |
| Thermal Design Power (TDP) | 150 W |
| Memory | |
| Maximum internal memory supported by processor | 4 TB |
| Memory types supported by processor | DDR5-SDRAM |
| Memory channels | Octa-channel |
| ECC | Yes |
| Graphics | |
| On-board graphics card | No |
| Discrete graphics card | No |
| On-board graphics card model | Not available |
| Discrete graphics card model | Not available |
| Features | |
| Execute Disable Bit | Yes |
| Maximum number of PCI Express lanes | 136 |
| PCI Express slots version | 5.0 |
| Scalability | 1S |
| Processor special features | |
| Intel© Hyper Threading Technology (Intel© HT Technology) | Yes |
| Intel© Turbo Boost Technology | 2.0 |
| Intel© AES New Instructions (Intel© AES-NI) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel© Speed Shift Technology | Yes |
| Intel© Transactional Synchronization Extensions | Yes |
| Intel© Total Memory Encryption | Yes |
| Intel© Control-flow Enforcement Technology (CET) | Yes |
| Intel© Crypto Acceleration | Yes |
| Intel© Platform Firmware Resilience Support | Yes |
| Intel© Trust Domain Extensions (Intel© TDX) | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel© Secure Key | Yes |
| Intel QuickAssist Technology | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel© Boot Guard | Yes |
| Intel© Deep Learning Boost (Intel© DL Boost) on CPU | Yes |
| Intel© Resource Director Technology (Intel© RDT) | Yes |
| Intel© Volume Management Device (VMD) | Yes |
| Intel© Run Sure Technology | Yes |
| Mode-based Execute Control (MBE) | Yes |
| Intel© Total Memory Encryption - Multi Key | Yes |
| Intel© QuickAssist Software Acceleration | Yes |
| Intel© Advanced Matrix Extensions (AMX) | Yes |
| Warranty | |
| Base Warranty | Non Non |
