Need a modern shared storage array which is flash-ready and affordable with what’s left of a small budget?
The HPE MSA 1060 Storage brings affordable flash storage down to the most price sensitive customers. Designed to meet entry-level storage requirements, the HPE MSA 1060 Storage is a good fit for budget constrained customers. With one of the lowest entry price points in the Hewlett Packard Enterprise Storage portfolio and field-proven HPE ProLiant compatibility, the HPE MSA 1060 Storage is the platform of choice for smaller IT workloads. The HPE MSA 1060 Storage features 10G-BaseT iSCSI, FC and SAS host interface connectivity at previously unattainable entry price points. The MSA 1060 allows users to take advantage of the latest storage technologies while also providing a balance between performance and budget.
Features
Accelerate Applications Affordably
- The HPE MSA 1060 Storage is capable of delivering over 150,000 IOPS for affordable application acceleration for small to medium-sized businesses and deployments.
- The MSA 1060 platform delivers allows users to define and deploy hybrid or flash configurations from day one and grow as needs change.
MSA’s 'Set and Forget' Data Services does not Require a Dedicated Storage Administrator to Manage
- The HPE MSA 1060 Storage is easy to install, easy to use, easy to maintain, even for an IT generalist. Administrators will find the MSA 1060’s new Storage Management Utility intuitive and easy to navigate.
- HPE MSA’s automated tiering engine dynamically responds to workload changes so you don’t have to, insuring the hottest data will be moved to the fastest media automatically and in real-time.
Leverage Data Protection Features to Keep your Business Running in the Event of a Disaster
- The HPE MSA 1060 Storage delivers virtualized snapshot technology making data protection and instant recovery a snap.
- Remote replication via Fibre Channel (FC) or iSCSI facilitates affordable disaster recovery solution.
Flexible, Modular Architecture that Facilitates Growth into the Future
- The HPE MSA1060 Storage supports a combination of 3.5 inch LFF and 2.5 inch SFF base enclosures to a maximum of 3 (4 including base system) enclosures.
- Start small and scale as needed with any combination of SSDs, Enterprise SAS HDDs or Midline SAS HDDs.
| Storage | |
| Storage drives installed | No |
| Installed storage drive type | No |
| Supported storage drive types | HDD & SSD |
| Number of storage drives supported | 24 |
| Maximum supported storage capacity | 368.64 TB |
| Supported storage drive interfaces | SAS |
| Storage drive sizes supported | 2.5" |
| RAID levels | 0, 1, 5, 6, 10 |
| Data transfer rate | 12 Gbit/s |
| Ports & interfaces | |
| USB connectivity | No |
| Host ports | 4 |
| Design | |
| Chassis type | Rack (2U) |
| Performance | |
| Device class | Small & Medium Business |
| Maximum number of controllers supported | 2 |
| Power | |
| Number of power supply units | 2 |
| AC input voltage | 100 - 230 V |
| AC input frequency | 50 - 60 Hz |
| System requirements | |
| Linux operating systems supported | Yes |
| Server operating systems supported | Windows Server 2016, Windows Server 2019 |
| Weight & dimensions | |
| Width | 445 mm |
| Depth | 508 mm |
| Height | 89 mm |
| Weight | 5 kg |
| Technical details | |
| Sustainability certificates | ENERGY STAR |
| Logistics data | |
| Harmonized System (HS) code | 84717020 |
| Other features | |
| Controller interface type | SAS |
| Clustering support | N |
| Insight manager support | N |
| SAN backup support | Y |
| Storage mirroring | Y |
| Warranty | |
| Base Warranty | Non Non |
