HPE 5901AF 48G 4XG 2QSFP+ Switch
ITCurry #: 1171ZJ58 | Article #: JL864A-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
The HPE Networking Comware Switch Series 5900 are high-density, low-latency top-of-rack (ToR) switches suited for deployment at the access layer and management network of medium-sized and large enterprise data centers. To meet the increased demand for virtualization, scalability, and programmability, these switches provide high-performance switching with low latency and a user-friendly operating system (OS) Comware v7. HPE Intelligent Resilient Fabric (IRF) helps create simpler, flatter, and more agile networks by combining multiple physical switches into a logical device. Network and security features, coupled with dual, redundant hot-swappable power supplies, provide investment protection, reliability, and availability, and allow advanced chassis power management. These switches also provide network visibility through multi-vendor network management with HPE Intelligent Management Center (IMC).
What is new supporting point:
Rich feature sets with IPv4 and IPv6 support Layer 2, Layer 3, and quality of service (QoS) / access control list (ACL) features.
Cut-through with low-latency and varying wire speed performance
HPE Intelligent Resilient Fabric (IRF) technology provides greater resilience and scalability
Introducing a new TAA-compliant top-of-rack switch with 48 × 1G Base-T, 4 × 10G SFP+, and 2 × 40G QSFP+ ports for secure and compliant deployments
Dual, redundant hot-pluggable power supplies with reversible airflow help reduce power consumption
OpenFlow™ and NETCONF™ for automating manual tasks and improving service delivery
| Management features | |
| Switch type | Managed |
| Switch layer | L3 |
| Quality of Service (QoS) support | Yes |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports type | No |
| SFP+ module slots quantity | 48 |
| Network | |
| Networking standards | IEEE 802.1D, IEEE 802.1Qau, IEEE 802.1Qaz, IEEE 802.1Qbb, IEEE 802.1ab, IEEE 802.1ag, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ah |
| 10G support | Yes |
| Flow control support | Yes |
| Link aggregation | Yes |
| Spanning tree protocol | Yes |
| VLAN support | Yes |
| Data transmission | |
| Switching capacity | 336 Gbit/s |
| Throughput | 250 Mpps |
| MAC address table | 16000 entries |
| Latency (10 Gbps) | 1.2 æs |
| Jumbo frames support | Yes |
| Packet buffer memory | 8 MB |
| Security | |
| DHCP features | DHCP client, DHCP server |
| Access Control List (ACL) | Yes |
| IGMP snooping | Yes |
| Protocols | |
| Routing protocols | BGP, IP, MPLS, OSPF, RIP, VRRP |
| Design | |
| Rack mounting | Yes |
| Stackable | Yes |
| Form factor | 1U |
| Product colour | Black |
| Performance | |
| Physical stacking (units) | 9 |
| Memory type | SDRAM |
| Internal memory | 2048 MB |
| Flash memory | 1024 MB |
| Power | |
| Power supply included | Yes |
| Redundant power supply (RPS) support | Yes |
| AC input voltage | 100 - 240 V |
| DC input voltage | 48 - 60 V |
| Power consumption (max) | 250 W |
| Power consumption note | 96 W (Dual AC) |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | No |
| Other features | |
| Latency | 1GE < 5 æs, 10GE< 3 æs, 40GE <1.2 æs (64-byte packets) |
| Memory and processor | 1 GB flash; Packet buffer size: 8 MB, 2 GB SDRAM |
| I/O ports | (48) autosensing 10/100/1000 ports, Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only, (4) fixed 1000/10000 SFP+ ports, (2) QSFP+ 40GbE ports |
| Non-operating relative humidity (non-condensing) | 10 - 90% |
| Performance management | HPE Intelligent Management Center (IMC) Command-line interface (CLI) Out-of-band management SNMP manager Telnet FTP |
| Weight (imperial) | 7.5 kg (16.5 lbs) |
| Dimensions (W x D x H) (imperial) | 439.9 x 359.9 x 43.9 mm (17.3 x 14.2 x 1.73") |
| Fan | 2 fan tray slots Fan trays are not included with the switch and must be ordered separately. Use two fan trays with matching airflow direction for proper operation. Do not run the system with one fan tray for over 24 hours or without any fan tray for more than two minutes. Operate within 23øF (-5øC) to 113øF (45øC). Not following these guidelines may void your warranty. |
| Operational conditions | |
| Operating temperature (T-T) | -5 - 45 øC |
| Operating relative humidity (H-H) | 10 - 90% |
| Heat dissipation | 327.6 BTU/h |
| Weight & dimensions | |
| Width | 440 mm |
| Depth | 360 mm |
| Height | 44 mm |
| Weight | 7.5 kg |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Warranty | |
| Base Warranty | Non Non |
