Ux10 G3 Ex - 10.1in - i7-1255u 16GB Ram - 256GB SSD - Win11 Pro
ITCurry #: T6696144 | Article #: USEE64WIX3SE-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
A versatile and portable ATEX and IECEx certified tablet ready to deliver digital transformation in potentially explosive environments where rugged performance is required.
ATEX AND IECEX CERTIFIED
Certified for hazardous environments, the UX10-EX fully rugged tablet offers optional ATEX and IECEx Zone 2/22 certification for use in potentially explosive atmospheres.
EXCEPTIONALLY ADAPTABLE RUGGED TABLET
Fast, tough, and adaptable, the UX10-EX tablet offers an exceptionally rugged computing experience. Featuring a 12th Generation Intel® i7/i5 processor and Thunderbolt™ 4, the IP66-certified UX10-EX delivers great performance with uncompromising security and durability, while an optional hard handle lets you conveniently carry it wherever it is needed. For total security in authenticating users, the UX10-EX has an optional RFID reader, and Windows Hello face-authentication camera, while its detachable keyboard with retractable hard handle further enhances worker productivity.
THE CONNECTED TABLET
Supporting seamless digital transformation, the UX10-EX offers digital connectivity through Bluetooth 5.3, Wi-Fi 6E AX211, and optional 4G LTE/5G, ensuring a stable connection even in highly congested environments. All these functionalities ensure that the UX10-EX stays connected wherever you need it, whether indoors or outdoors.
THE EVEN MORE RUGGED TABLET
The UX10-EX is a new level of ruggedness, certified with the IP66 and military-grade MIL-STD 810H standards. It resists water, dust, vibration, and will withstand temperatures from 0°C to +55°C (32°F to 131°F), and a 6-foot (1.8m) drop while operating.
THE USABLE-IN-ALL CONDITIONS TABLET
Paired with its superior drop resistance and temperature tolerance, the UX10-EX’s LumiBond screen ensures usability in all conditions. 1000 nits of brightness make the display readable even in sunlight, while its rain and glove touch capability guarantee visibility and productivity even in many extreme conditions.
| Display | |
| Display diagonal | 25.6 cm (10.1") |
| Display resolution | 1920 x 1200 pixels |
| Panel type | TFT |
| Display brightness | 1000 cd/mý |
| HD type | WUXGA |
| Processor | |
| Processor manufacturer | Intel |
| Processor family | Intel© CoreT i7 |
| Processor model | i7-1255U |
| Processor cores | 10 |
| Processor boost frequency | 4.7 GHz |
| Performance cores | 2 |
| Efficient cores | 8 |
| Performance-core Max Turbo Frequency | 4.7 GHz |
| Efficient-core Max Turbo Frequency | 3.5 GHz |
| Processor cache | 12 MB |
| Memory | |
| Internal memory | 16 GB |
| Internal memory type | DDR4-SDRAM |
| Storage | |
| Internal storage capacity | 256 GB |
| Card reader integrated | No |
| Storage media | SSD |
| SSD interface | PCI Express |
| NVMe | Yes |
| Graphics | |
| Graphics card family | Intel |
| Graphics card | UHD Graphics |
| Camera | |
| Rear camera type | Single camera |
| Rear camera resolution (numeric) | 8 MP |
| Front camera | Yes |
| Front camera resolution (numeric) | 5 MP |
| Network | |
| Mobile network connection | No |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Ports & interfaces | |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| Thunderbolt technology | Yes |
| Thunderbolt 4 ports quantity | 1 |
| Combo headphone/mic port | Yes |
| DC-in jack | Yes |
| Design | |
| Device type | Tablet PC |
| Form factor | Slate |
| Product colour | Black |
| Protection features | Drop proof, Dust resistant, Freeze resistant, Heat resistant, Vibration proof, Water resistant |
| International Protection (IP) code | IP66 |
| Performance | |
| Trusted Platform Module (TPM) | Yes |
| Security | |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Software | |
| Platform | Windows |
| Operating system installed | Windows 11 Pro |
| Battery | |
| Battery technology | Lithium-Ion (Li-Ion) |
| Battery capacity | 4200 mAh |
| Battery voltage | 11.1 V |
| Power | |
| AC adapter power | 65 W |
| AC adapter input voltage | 100-240 V |
| AC adapter frequency | 50/60 Hz |
| USB Type-C charging port | No |
| USB Power Delivery (USB PD) | No |
| Weight & dimensions | |
| Width | 279 mm |
| Depth | 194 mm |
| Height | 23.9 mm |
| Weight | 1.38 kg |
| Packaging content | |
| Stylus pen | Yes |
| AC adapter included | Yes |
| Certificates | |
| Certification | MIL-STD-810H, ATEX & IECEx |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 55 øC |
| Storage temperature (T-T) | -51 - 71 øC |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Warranty | |
| Base Warranty | Non Non |
