Product Information
Single-arm full-motion TV wall mount
 Supports most 32'' - 55'' LCD TV’s
 VESA compatible, max. 400 mm x 400 mm
 Wall distance 105 - 429 mm
 Allows up to 180 degrees swivel and 23 degrees tilting
 Practical integrated bubble level for perfect alignment
 Includes all necessary installation materials
| Mounting | |
| Maximum weight capacity | 35 kg |
| Minimum screen size | 81.3 cm (32") |
| Number of displays supported | 1 |
| Maximum screen size | 139.7 cm (55") |
| Minimum VESA mount | 75 x 75 mm |
| Maximum VESA mount | 400 x 400 mm |
| Panel mounting interface | 75 x 75,100 x 100,100 x 150,100 x 200,150 x 100,150 x 150,200 x 100,200 x 200,300 x 300,300 x 200,400 x 200,400 x 400,400 x 300 |
| Mounting type | Wall |
| Ergonomics | |
| Tilt adjustment | Yes |
| Tilt angle range | 5 - -18ø |
| Swivelling | Yes |
| Swivel angle range | 90 - -90ø |
| Turn angle | 180ø |
| Cable management | Yes |
| Distance to the wall (max) | 42.9 cm |
| Distance to the wall (min) | 10.5 cm |
| Design | |
| Product colour | Black |
| Housing material | Plastic, Steel |
| Technical details | |
| Sustainability compliance | Yes |
| Compliance certificates | RoHS |
| Packaging content | |
| Manual | Yes |
| Mounting kit | Yes |
| Weight & dimensions | |
| Width | 429 mm |
| Depth (max) | 43 cm |
| Height | 430 mm |
| Weight | 2.3 kg |
| Packaging data | |
| Package width | 166 mm |
| Package depth | 450 mm |
| Package height | 97 mm |
| Package weight | 2.81 kg |
| Package type | Box |
| Warranty | |
| Base Warranty | Non Non |
