Et50/55 8in Docking Station With 12-32 Vdc Isolated Power Supply
ITCurry #: U8412015 | Article #: 7170-0522-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
This kit includes a dock (7160-0788-00) to hold your tablet, full port replication, and a Lind power supply to keep it charged. Currently available in Europe only, coming soon to U.S.
- Port repolications for ethernet RJ45 (1), USB
- 3.0 9-pin (3), HDMI 19 pin, power input.
- Designed and tested for MIL-STD 810G specifications.
- Compatible with Zebra enterprise tablets with the rugged frame option.
- Accommodates expansion back of the ET50/55 to easily add accessories like a scanner/hand strap, battery bay, or stylus.
- Front camera on ET50/55 accessible when the tablet is in the docking station.
- Compatible with Windows or Android operating systems.
- Dual latch/locks provide stability and docking connectivity.
- Guide pins prevent damage to the docking connection when docking the tablet.
- VESA 75mm mounting pattern.
- Steel and composite design for reduced weight
- Rugged construction for long-term durability.
| Performance | |
| Basic device type | Tablet |
| Brand compatibility | Zebra |
| Compatibility | Zebra ET50/55 8" |
| Product colour | Black |
| Material | Steel |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| HDMI | Yes |
| HDMI connector type | Full-size |
| Ethernet LAN (RJ-45) ports | 1 |
| Power | |
| Power source type | DC |
| Weight & dimensions | |
| Width | 229 mm |
| Depth | 85 mm |
| Height | 254 mm |
| Weight | 1.18 kg |
| Packaging data | |
| Quantity | 1 |
| Logistics data | |
| Harmonized System (HS) code | 84719000 |
| Warranty | |
| Base Warranty | Non Non |
