Primergy Tx1330 M5 Tower Server - E-2334 - 16GB Ram - No HDD
ITCurry #: 1855Z059 | Article #: VFY:T1325SC011IN-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
The unique ultra-compact Fujitsu Server PRIMERGY TX1320 M5 has advanced technology
ideal for most industry verticals, small and medium-sized enterprises (SME), spaceconstrained environments, retail premises or branch offices. The performance-oriented yet costeffective mono-socket design supports the latest Intel® Xeon® E-2300 product family processors, an
affordable Pentium® processor option plus up to 128 GB RAM at 3,200 MT/s to boost performance
for appropriately sized standard business workloads, including virtualized ones (such as:
file/print, email, ERP/CRM, messaging, centralizeddata storage) and industry specific applications.
Institutions with special legal requirements such as medical, governmental, legal, or financial
offices can benefit from the server’s secure and robust storage and transmission features. These
include up to eight high quality 2.5-inch storage devices (including up to four ultra-fast PCIe SSDs
for demanding applications), powerful RAID controllers, graphics and networking options
enabled by 4 PCIe expansion slots (Gen 4/3) together with versatile and affordable backup plus
TPM 2.0 capability. High efficiency (94%), 500W redundant power supplies enhance reliability and protect customer investment. This ultra-compact,silent server with a new dust protection kit and
Advanced Thermal Design Technology is designed for deployment flexibility – it can be deployed in
offices, on rack shelves, industrial areas and even on desks at temperatures from 5 °C to 45 °C. New
generation technologies include M.2 modules for efficient OS installation along with dual microSD
capability for VMware ESXi, plus the latest USB 3.2 Gen 2 ports. Furthermore, the TX1320 M5
server features the iRMC S6 and the Fujitsu Infrastructure Manager (ISM) suite, which enable
remote server management and centralized IT infrastructure control respectively, hence boosting
IT administrator productivity
| Processor | |
| Processor manufacturer | Intel |
| Processor family | Intel Xeon E |
| Processor model | E-2334 |
| Processor frequency | 3.4 GHz |
| Processor boost frequency | 4.8 GHz |
| Processor cache | 8 MB |
| Motherboard chipset | Intel C256 |
| Number of processors installed | 1 |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Memory | |
| Internal memory | 16 GB |
| Internal memory type | DDR4-SDRAM |
| Memory slots | 4x DIMM |
| ECC | Yes |
| Memory clock speed | 3200 MHz |
| Memory layout (slots x size) | 1 x 16 GB |
| Maximum internal memory | 128 GB |
| Storage | |
| RAID support | Yes |
| RAID levels | 0, 1, 5, 6 |
| Hot-Plug support | Yes |
| Optical drive type | No |
| Network | |
| LAN controller | Intel I210 |
| Ethernet LAN | Yes |
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet interface type | Gigabit Ethernet |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 2 |
| USB 2.0 ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| VGA (D-Sub) ports quantity | 1 |
| DisplayPorts quantity | 1 |
| Total number of SATA connectors | 7 |
| Expansion slots | |
| PCI Express x4 (Gen 3.x) slots | 2 |
| PCI Express x8 (Gen 4.x) slots | 2 |
| Design | |
| Chassis type | Tower |
| Performance | |
| Remote administration | iRMCS6 |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Software | |
| Operating system installed | No |
| Compatible operating systems | Windows Server 2022 Datacenter Windows Server 2022 Standard Windows Server 2022 Essentials Windows Server 2019 Datacenter Windows Server 2019 Standard Windows Server 2019 Essentials VMware vSphereT 7.0 SUSE© Linux Enterprise Server 15 Red Hat© Enterprise Linux 8 |
| Processor special features | |
| CPU configuration (max) | 1 |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Power | |
| Power supply | 500 W |
| Number of redundant power supplies supported | 2 |
| Operational conditions | |
| Operating temperature (T-T) | 5 - 45 øC |
| Operating relative humidity (H-H) | 8 - 85% |
| Weight & dimensions | |
| Width | 98 mm |
| Depth | 400 mm |
| Height | 340 mm |
| Warranty | |
| Base Warranty | Non Non |
