Ridge Black Mitx Pci-e 4.0
ITCurry #: S5842575 | Article #: FD-C-RID1N-11-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
An uncluttered, small form factor case designed to integrate seamlessly into your living space and daily rituals. An evolution of the slimline format, Ridge was developed in collaboration with gaming and entertainment enthusiasts to subtly improve their homes and enhance the small form factor PC experience.
Find your balance
Maximized capability with a minimized footprint
Inch-perfect efficiency
- Meticulously engineered to maximize its capability while minimizing its footprint
- Small form factor case with a volume of 12.6 liters
- Supports GPUs up to a length of 335 mm
Horizontal or vertical
- Multiple feet configurations allow for both horizontal and vertical orientation
- Elevate any gaming desk, workspace or entertainment area
Unrivalled access
Remove any panel to gain easy access to every side of your build
All-around ventilation
- Ventilated on all sides to maximize its cooling potential
- Comes with 2x 140 mm PWM Aspect fans pre-installed
- Supports 2x 120/140 mm and 3x 80 mm fans
Well-balanced design
- Stylish fabric front with CNC machined aluminum frame
- Features a Power LED bar in front
Type-C interface
Front I/O comes with 2x USB 3.0, 1x USB type-C and a combined mic and headphone jack
Smart configurations
- Comes with our own PCIe 4.0 or PCIe 3.0 riser card pre-installed
- Four 2.5” drive mounts included
| Design | |
| Material | Steel |
| Form factor | Small Form Factor (SFF) |
| Type | PC |
| Product colour | Black |
| Supported motherboard form factors | Mini-ITX |
| Number of 2.5" bays | 4 |
| Number of expansion slots | 3 |
| Cable management | Y |
| On/off button | Y |
| LED indicators | Power |
| Maximum CPU cooler height | 7 cm |
| Maximum graphics card length | 33.5 cm |
| Power supply | |
| Power supply included | N |
| Supported power supply form factors | SFX, SFX-L |
| Ports & interfaces | |
| Audio input | Y |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| Cooling | |
| Side fans installed | 2x 140 mm |
| Number of side fans supported (max) | 2 |
| Side fans diameters supported | 120,140 mm |
| Number of top fans supported (max) | 3 |
| Top fans diameters supported | 80 mm |
| Side radiator sizes supported | 120,280 mm |
| Storage | |
| Supported HDD sizes | 2.5" |
| SSD form factor | 2.5" |
| Packaging content | |
| Manual | Y |
| Weight & dimensions | |
| Width | 110 mm |
| Depth | 374 mm |
| Height | 395 mm |
| Weight | 4.3 kg |
| Packaging data | |
| Package width | 167 mm |
| Package depth | 426 mm |
| Package height | 431 mm |
| Package weight | 5.5 kg |
| Warranty | |
| Base Warranty | Non Non |
