Tm-h6000v-21 - Integrated Pos Printer - Thermal - 83mm - USB / Serial - White
ITCurry #: 1925U328 | Article #: C31CG62213-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Integrated POS printer
Offering receipt printing, slip printing and cheque processing in one unit, this integrated POS printer offers a range of features and low TCO
This integrated point-of-sale printer is capable of receipt printing, slip printing and cheque processing in one unit. It's reliable, provides useful connectivity features and offers a very low total cost of ownership. It's ideal for businesses requiring cheque-processing facilities at point of sale, and print receipts with the same unit.
More productivity
Ideal for busy environments, the TM-H6000V offers a selection of features that help businesses boost overall efficiency. It prints at speeds up to 350mm/s¹, offers fast cheque processing and a swift auto-cutter.
Reliable and efficient
In fast paced environments, it's essential to minimise downtime. The TM-H6000V is a dependable solution with the thermal printer now effective for 200km of receipts, while its auto-cutter is capable of three million cuts.
Range of connectivity features
The TM-H6000V is designed to handle all types of POS solutions with ease. It's flexible enough to adapt to the demands of modern retail environments including Server Direct Print (SDP) to print and display data from external servers, as well as multiple interfaces for tablet and PC coexistence.
Stay tuned with the trends in the POS Market
Looking for a future-proof printer that's simple and quick to set-up? ePOS-Print, ePOS-display and NFC tagging make it possible to incorporate new functionalities at the Point of Sale and allow quick tablet POS set-up.
| Printing | |
| Colour | No |
| Maximum resolution | 180 x 180 DPI |
| Print speed | 5.7 lps |
| Print speed | 350 mm/sec |
| Print speed (receipt) | 350 mm/sec |
| Character size | 1.24 x 3.11 mm |
| Character density | 17.8 cpi |
| Printing characters | Text, Graphic, Barcode |
| Character sets | ANK |
| Print technology | Dot matrix |
| Type | POS printer |
| Paper handling | |
| Maximum roll diameter | 8.3 cm |
| Supported paper width | 80 mm |
| Maximum paper size (slip) | 230 x 297 mm |
| Ports & interfaces | |
| USB port | Yes |
| USB connector | USB Type-A / USB Type-B |
| Serial interface | Yes |
| Serial interface type | RS-232 |
| Connectivity technology | Wired & Wireless |
| Near Field Communication (NFC) | Yes |
| Standard interfaces | Ethernet, NFC, RS-232, USB 1.1, USB 2.0 |
| Network | |
| Ethernet LAN | Yes |
| Features | |
| Sound pressure level (printing) | 55 dB |
| Sound pressure level (standby) | 55 dB |
| Mean time between failures (MTBF) | 180000 h |
| Cutter | Yes |
| Half-cutter | Yes |
| Autocutter durability | 3 million cuts |
| Built-in MICR | Yes |
| Paper save function | Yes |
| Print head life | 200 km |
| Country of origin | China |
| Maximum number of copies (slip) | 3 copies |
| Printer receipt unit life | 20000000 lines |
| Printer slip unit life | 27000000 lines |
| Ribbon life (slip) | 4 million characters |
| Built-in sensors details | Middle of Paper pass sensor, Front cover open sensor, Roll paper cover open sensor, Paper End Sensor, Top of Form sensor, Bottom of Form sensor, Slip eject sensor, Receipt near-end sensor |
| Certification | CE, EN55024, EN55032 Class A, IEC61000-4-2, IEC61000-4-3, IEC61000-4-4, IEC61000-4-5, IEC61000-4-6, IEC61000-4-11, Directive 2014/30/EU |
| Design | |
| Product colour | White |
| Power | |
| AC input voltage | 24 V |
| Operational conditions | |
| Operating temperature (T-T) | 5 - 45 øC |
| Storage temperature (T-T) | -10 - 50 øC |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 10 - 90% |
| System requirements | |
| Pre-installed software | Server Direct Print, ePOS-Display, ePOS-Print |
| Weight & dimensions | |
| Width | 186 mm |
| Depth | 278 mm |
| Height | 181 mm |
| Weight | 4.4 kg |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
| Package width | 294 mm |
| Package depth | 382 mm |
| Package height | 292 mm |
| Package weight | 5.67 kg |
| Packaging content | |
| AC adapter included | Yes |
| Print technology | |
| Column capacity | 45 cps / 60 cps |
| Logistics data | |
| Harmonized System (HS) code | 84433210 |
| Products per pallet | 56 pc(s) |
| Products per pallet layer | 8 pc(s) |
| Pallet gross width | 80 cm |
| Pallet gross length | 120 cm |
| Pallet gross height | 2.18 m |
| Products per pallet (UK) | 70 pc(s) |
| Products per pallet layer (UK) | 10 pc(s) |
| Pallet width (UK) | 100 cm |
| Pallet length (UK) | 120 cm |
| Pallet height (UK) | 2.18 m |
| Technical details | |
| Font size | 1.41 mm (W) x 3.39 mm (H) / 0.99 mm (W) x 2.4 mm (H) |
| Changeable interface | Y |
| Other features | |
| Buffer size | 4 KB |
| Mean cycles between failures (MCBF) | 65000000 |
| Print head life | 200000000 million characters |
| Warranty | |
| Base Warranty | Non Non |
