Product Information

Integrated POS printer
Offering receipt printing, slip printing and cheque processing in one unit, this integrated POS printer offers a range of features and low TCO

This integrated point-of-sale printer is capable of receipt printing, slip printing and cheque processing in one unit. It's reliable, provides useful connectivity features and offers a very low total cost of ownership. It's ideal for businesses requiring cheque-processing facilities at point of sale, and print receipts with the same unit.

More productivity
Ideal for busy environments, the TM-H6000V offers a selection of features that help businesses boost overall efficiency. It prints at speeds up to 350mm/s¹, offers fast cheque processing and a swift auto-cutter.

Reliable and efficient
In fast paced environments, it's essential to minimise downtime. The TM-H6000V is a dependable solution with the thermal printer now effective for 200km of receipts, while its auto-cutter is capable of three million cuts.

Range of connectivity features
The TM-H6000V is designed to handle all types of POS solutions with ease. It's flexible enough to adapt to the demands of modern retail environments including Server Direct Print (SDP) to print and display data from external servers, as well as multiple interfaces for tablet and PC coexistence.

Stay tuned with the trends in the POS Market
Looking for a future-proof printer that's simple and quick to set-up? ePOS-Print, ePOS-display and NFC tagging make it possible to incorporate new functionalities at the Point of Sale and allow quick tablet POS set-up.

Printing
Colour No
Maximum resolution 180 x 180 DPI
Print speed 5.7 lps
Print speed 350 mm/sec
Print speed (receipt) 350 mm/sec
Character size 1.24 x 3.11 mm
Character density 17.8 cpi
Printing characters Text, Graphic, Barcode
Character sets ANK
Print technology Dot matrix
Type POS printer
Paper handling
Maximum roll diameter 8.3 cm
Supported paper width 80 mm
Maximum paper size (slip) 230 x 297 mm
Ports & interfaces
USB port Yes
USB connector USB Type-A / USB Type-B
Serial interface Yes
Serial interface type RS-232
Connectivity technology Wired & Wireless
Near Field Communication (NFC) Yes
Standard interfaces Ethernet, NFC, RS-232, USB 1.1, USB 2.0
Network
Ethernet LAN Yes
Features
Sound pressure level (printing) 55 dB
Sound pressure level (standby) 55 dB
Mean time between failures (MTBF) 180000 h
Cutter Yes
Half-cutter Yes
Autocutter durability 3 million cuts
Built-in MICR Yes
Paper save function Yes
Print head life 200 km
Country of origin China
Maximum number of copies (slip) 3 copies
Printer receipt unit life 20000000 lines
Printer slip unit life 27000000 lines
Ribbon life (slip) 4 million characters
Built-in sensors details Middle of Paper pass sensor, Front cover open sensor, Roll paper cover open sensor, Paper End Sensor, Top of Form sensor, Bottom of Form sensor, Slip eject sensor, Receipt near-end sensor
Certification CE, EN55024, EN55032 Class A, IEC61000-4-2, IEC61000-4-3, IEC61000-4-4, IEC61000-4-5, IEC61000-4-6, IEC61000-4-11, Directive 2014/30/EU
Design
Product colour White
Power
AC input voltage 24 V
Operational conditions
Operating temperature (T-T) 5 - 45 øC
Storage temperature (T-T) -10 - 50 øC
Operating relative humidity (H-H) 10 - 90%
Storage relative humidity (H-H) 10 - 90%
System requirements
Pre-installed software Server Direct Print, ePOS-Display, ePOS-Print
Weight & dimensions
Width 186 mm
Depth 278 mm
Height 181 mm
Weight 4.4 kg
Packaging data
Quantity per pack 1 pc(s)
Package width 294 mm
Package depth 382 mm
Package height 292 mm
Package weight 5.67 kg
Packaging content
AC adapter included Yes
Print technology
Column capacity 45 cps / 60 cps
Logistics data
Harmonized System (HS) code 84433210
Products per pallet 56 pc(s)
Products per pallet layer 8 pc(s)
Pallet gross width 80 cm
Pallet gross length 120 cm
Pallet gross height 2.18 m
Products per pallet (UK) 70 pc(s)
Products per pallet layer (UK) 10 pc(s)
Pallet width (UK) 100 cm
Pallet length (UK) 120 cm
Pallet height (UK) 2.18 m
Technical details
Font size 1.41 mm (W) x 3.39 mm (H) / 0.99 mm (W) x 2.4 mm (H)
Changeable interface Y
Other features
Buffer size 4 KB
Mean cycles between failures (MCBF) 65000000
Print head life 200000000 million characters
Warranty
Base Warranty Non Non
