Ext1109p 3xge 4xge Poe 1xge Pd Switch Extender With 1 Sfp Port
ITCurry #: Q4342259 | Article #: EXT1109P-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
EnGenius Switch Extender, EXT1109P is a reliable 4-Port GE PoE, 1-Port GE PD PoE, 3 GE Ports and 1 SFP slot switch that excels in diversifying network expansion. Its SFP interface extends data transmission beyond the traditional 100-meter RJ45 limit, ensuring robust network performance. Its optimized Voice-VLAN feature, zero-touch provisioning, and easy-to-use cloud-based management provide SMBs with a hassle-free network solution.
Extend Your Network Beyond 100 Meters: Beyond RJ45’s Limitations
Expand network coverage beyond 100 meters effectively with an advanced SFP interface, ensuring extended reach without compromising performance.
Enhancing Network Efficiency: Advanced Built-in Switch Capabilities
Maximize network efficiency with built-in switch features: VLAN for streamlined data management, IGMP Snooping for multicast traffic optimization, and RSTP for enhanced network resilience, all ensuring optimal performance across various applications.
| Management features | |
| Switch layer | L2 |
| Quality of Service (QoS) support | Yes |
| Cloud-managed | Yes |
| System event log | Yes |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity | 8 |
| Fiber ports quantity | 1 |
| Fiber optic connector | SFP |
| Network | |
| Networking standards | IEEE 802.1Q, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u |
| 10G support | No |
| Copper ethernet cabling technology | 100BASE-TX, 1000BASE-T |
| Spanning tree protocol | Yes |
| VLAN support | Yes |
| Virtual LAN features | Port-based VLAN, Voice VLAN |
| Data transmission | |
| Switching capacity | 18 Gbit/s |
| MAC address table | 8000 entries |
| Jumbo frames support | Yes |
| Jumbo frames | 10000 |
| Security | |
| IGMP snooping | Yes |
| Queue scheduling algorithms | Weighted Round Robin (WRR) |
| Multicast features | |
| Multicast support | Yes |
| Design | |
| Rack mounting | No |
| Product colour | Grey |
| LED indicators | Activity, Link, PoE, Power |
| Performance | |
| Flash memory | 32 MB |
| Power | |
| Power source | DC/PoE |
| Power supply included | Yes |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) ports quantity | 5 |
| Power over Ethernet (PoE) power per port | 30 W |
| Total Power over Ethernet (PoE) budget | 90 W |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 øC |
| Operating relative humidity (H-H) | 5 - 95% |
| Weight & dimensions | |
| Width | 105 mm |
| Depth | 240 mm |
| Height | 27 mm |
| Weight | 620 g |
| Packaging data | |
| Package width | 270 mm |
| Package depth | 166 mm |
| Package height | 84 mm |
| Package weight | 1.1 kg |
| Logistics data | |
| Master (outer) case net weight | 11 kg |
| Master (outer) case width | 357 mm |
| Master (outer) case length | 452 mm |
| Master (outer) case height | 271 mm |
| Harmonized System (HS) code | 85176990 |
| Master (outer) case gross weight | 11.8 kg |
| Products per master (outer) case | 10 pc(s) |
| Warranty | |
| Base Warranty | Non Non |
