Touchpro Display Modules 7in
ITCurry #: M0134505 | Article #: E271156-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Elo's Touchscreen Display Modules combine industry-leading touch screens with liquid crystal displays (LCDs) - all in one embedded solution to help streamline your supply chain and simplify assembly.
The robust chemically strengthened cover glass with anti-glare treatment makes them well suited for deployment in a wide variety of commercial and industrial environments - from factory automation and medical displays to commercial kitchen equipment.
Available in standard sizes ranging from 7 to 15.6-inches and custom options up to 32-inches, Elo’s touchscreen display modules offer superior touch performance in harsh environments, excellent optical clarity, and robust EMI performance.
How it Works
With a TouchPro Pro-F PCAP touch screen and chip-on-flex (COF) touch controller bonded to a commercial grade LCD, Elo’s Touchscreen Display Modules deliver reliability that is ready for integration.
Customize Your LCM
From design and engineering to prototyping and production, partner with Elo to create your touchscreen display module. By leveraging our premium PCAP touch screens, display expertise and LCD buying power, Elo can help you develop the perfect touch enabled display for your application.
| Display | |
| Display diagonal | 17.8 cm (7") |
| Display resolution | 800 x 480 pixels |
| Display technology | LCD |
| Touchscreen | Y |
| Touchscreen type | Multi-user |
| Touchscreen technology | Projected capacitive system |
| Touch technology | Multi-touch |
| Number of simultaneous touchpoints | 10 |
| Screen shape | Flat |
| Viewing angle, horizontal | 160ø |
| Viewing angle, vertical | 160ø |
| Viewable size, horizontal | 15.3 cm |
| Viewable size, vertical | 9.24 cm |
| Display brightness | 400 cd/mý |
| Performance | |
| NVIDIA G-SYNC | N |
| AMD FreeSync | N |
| Multimedia | |
| Built-in camera | N |
| Built-in microphone | N |
| Design | |
| Product colour | Black |
| Glass thickness | 1.1 mm |
| Ports & interfaces | |
| USB Touch port | Y |
| Warranty | |
| Base Warranty | Non Non |
| Operational conditions | |
| Operating temperature (T-T) | -30 - 85 øC |
| Weight & dimensions | |
| Width (without stand) | 18.3 cm |
| Height (without stand) | 12.4 cm |
| Other features | |
| Mean time between failures (MTBF) | 50000 h |
