LCD Monitor - 2703lm - 27in - Fhd - USB-c - Pcap 10 Touch - Dicom - Black (e381844)
ITCurry #: M0134737 | Article #: E381844-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
DICOM Medical Grade Touchscreen Monitors
The 03-Series Medical Grade Touchscreen Monitors merge best-in-class touchscreen technology with DICOM Part 14 functionality to help enhance clinical review for healthcare providers while increasing patient engagement. With a compact form factor and sleek design, the touchscreen monitors are well-suited for EMR documentation, image viewing, clinical collaboration, deployment within the laboratory and pharmacy and for integration into medical devices.
Easy to Clean
Increase safety for healthcare providers and patients with the easy-to-clean touchscreen displays.
DICOM 14 - Designed for Consistent Image Review
Get the image accuracy you need during clinical review with the 03-Series medical grade touch screen monitors. To help ensure healthcare providers and patients can view clear, accurate and consistent medical images, the displays are pre-calibrated from the factory per AAPM secondary display guidelines in compliance with the DICOM 14 GSDF curve.
Enhancing Clinical Workflow with Touch
From analyzing X-rays and scans to reviewing vitals, lab results and medical history, adding touchscreens into the clinical workflow creates efficiencies while improving the patient and provider experience.
Enhancing Clinical Workflow with Touch
From analyzing X-rays and scans to reviewing vitals, lab results and medical history, adding touchscreens into the clinical workflow creates efficiencies while improving the patient and provider experience.
Purpose-built for Healthcare
The 03-Series medical grade touch screen monitors offer flexibility for installation in a variety of healthcare environments to support increased communication among patients and healthcare providers.
Medical Device Ready
With a full line of touch technologies and display solutions, Elo can help develop and customize products for almost any medical device including ventilator monitors, anesthesia monitors, patient monitors and medication dispensers. From operating rooms to patient rooms, laboratories and anywhere healthcare is provided, Elo products are well-suited for medical applications where consistent and long-lasting quality and touch performance are critical.
Configurability Made Easy
Flexible Mounting
Every monitor is designed with VESA hole patterns to simplify mounting onto a variety of stands, arms, walls or medical carts.
Privacy Matters
Optional privacy filters offer an additional safeguard when reviewing private health information or sensitive administrative data.
Ergonomic
Optional handles can be added to easily move or rotate the display to a comfortable orientation.
| Display | |
| Display diagonal | 68.6 cm (27") |
| Display resolution | 1920 x 1080 pixels |
| HD type | Full HD |
| Native aspect ratio | 16:9 |
| Display technology | LCD |
| Panel type | TFT |
| Touchscreen | Yes |
| Touchscreen technology | Projected capacitive system |
| Number of simultaneous touchpoints | 10 |
| Response time | 14 ms |
| Anti-glare screen | Yes |
| Screen shape | Flat |
| Supported graphics resolutions | 640 x 400, 640 x 480 (VGA), 720 x 400, 800 x 500, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1366 x 768, 1440 x 900 (WXGA+), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080) |
| Contrast ratio (typical) | 1000:1 |
| Maximum refresh rate | 70 Hz |
| Viewing angle, horizontal | 178ø |
| Viewing angle, vertical | 178ø |
| Display number of colours | 16.7 million colours |
| Horizontal scan range | 30 - 82 kHz |
| Vertical scan range | 50 - 75 Hz |
| Viewable size, horizontal | 59.8 cm |
| Viewable size, vertical | 33.6 cm |
| Display diagonal (metric) | 68.6 cm |
| Display brightness | 300 cd/mý |
| Multimedia | |
| Built-in speaker(s) | Yes |
| Built-in camera | No |
| RMS rated power | 2 W |
| Design | |
| Market positioning | Medical |
| Product colour | White |
| International Protection (IP) code | IP54 |
| Certification | UL: AAMI /ANSI ES60601-1:2005/(R)2012 and A1:2012, C1:2009/(R)2012 and A2:2010/(R)2012/IEC 60601-1 Ed. 3.1 cUL: (CAN/CSA-C22.2 NO. 60601-1:14 /IEC60601-1 Ed. 3.1 CB: IEC 60601-1:2005+A1:2012 (Ed. 3.1) CE: IEC 60601-1-2:2014 (Ed. 4) Risk Management: ISO 14971:2007 + EN ISO 14971:2012 Usability: IEC 60601-1-6:2010+A1:2013 (Ed. 3.1), IEC 62366:2007+A1:2014 (Ed. 1.1) |
| Ports & interfaces | |
| USB version | 2.0 |
| VGA (D-Sub) ports quantity | 1 |
| HDMI | Yes |
| HDMI ports quantity | 1 |
| Headphone connectivity | 3.5 mm |
| DC-in jack | Yes |
| Ergonomics | |
| VESA mounting | Yes |
| Wall mountable | Yes |
| On Screen Display (OSD) | Yes |
| On Screen Display (OSD) languages | Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese |
| Number of OSD languages | 10 |
| LED indicators | Power |
| Power | |
| Energy efficiency class (SDR) | E |
| Energy consumption (SDR) per 1000 hours | 21 kWh |
| Power consumption (typical) | 17.37 W |
| Power consumption (standby) | 1 W |
| Power consumption (max) | 22.41 W |
| Power consumption (off) | 0.24 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 / 60 Hz |
| Energy efficiency scale | A to G |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 øC |
| Storage temperature (T-T) | -20 - 60 øC |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 95% |
| Packaging content | |
| Cables included | HDMI, USB, VGA |
| Weight & dimensions | |
| Width (without stand) | 394.1 mm |
| Depth (without stand) | 44.9 mm |
| Height (without stand) | 647.6 mm |
| Weight (without stand) | 7.13 kg |
| Packaging data | |
| Package width | 520 mm |
| Package depth | 187 mm |
| Package height | 770 mm |
| Package weight | 10.4 kg |
| Sustainability | |
| Sustainability compliance | Yes |
| Sustainability certificates | BIS, BSMI, CB, CE, China Compulsory Certification (CCC), China RoHS, EAC, Federal Communications Commission (FCC), KCC, RCM, REACH, RoHS, UKCA, VCCI, WEEE, cUL |
| European Product Registry for Energy Labelling (EPREL) code | 361244 |
| Technical details | |
| Box contents | Touchmonitor Quick Install Guide 3x Tie wraps VGA cable HDMI cable Touch USB cable Audio cable Power brick (E323104) NA Power cable EU Power cable EEI Label DICOM calibration sheet 4 x VESA Screws (only for E381654 and E381844) 4 x rubbers (only for E381654 and E381844, affix to VESA holes) 2 x Cable cover screws |
| Compliance certificates | BIS, BSMI, CB, CE, China Compulsory Certification (CCC), China RoHS, EAC, Federal Communications Commission (FCC), KCC, RCM, REACH, RoHS, UKCA, VCCI, WEEE, cUL |
| Other features | |
| Display viewable area (HxV) | 597.88 x 336.31 mm |
| Placement supported | Indoor |
| USB connector type | Micro-USB, USB Type-A, USB Type-B |
| Power consumption (sleep) | 1.006 W |
| Active display area (W x H) | 597.88 x 336.31 mm |
| USB 2.0 ports quantity | 1 |
| USB ports quantity | 6 |
| Mean time between failures (MTBF) | 50000 h |
| Warranty | |
| Base Warranty | Non Non |
