Esy15i3 Black 15.6in - 3GB Ram - 32GB SSD - Android 8.1 - Pcap 10-touch In - With 2d Barcode Scanner (n3680) And Poe Module
ITCurry #: M0134508 | Article #: E509874-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Elo's I-Series 3.0 for Android delivers a reliable, commercial-grade solution with the flexibility and functionality of Google Play Services. Based on a unified architecture, Elo's Android-powered devices make it easy to create a seamless experience for your customers - from their mobile devices to your interactive in-store experiences.
Purpose-built with a modular design, the I-Series can be found in installations across the globe, from in-store interaction and point of sale to self-service, hospitality and corporate office environments. The uses are limitless.
You can deploy and manage your Android devices with EloView and take advantage of the latest Google Mobile Services features. Available with your choice of size and configuration, the 3.0 Android-platform is designed to offer versatility across environments with the durability to meet the demands of continuous public use.
I-Series for Everything
Our I-Series for Android has proven a versatile workhorse. From self-order kiosks and point-of-sale systems to in-store interaction, kitchen display systems, price checkers and meeting room signage, the I-Series is well-suited to meet the demands of continuous daily use.
Google Play Services
Now you can create a seamless experience for your customers - from their personal devices to your interactive experiences in store. With Google Play Services, your app can take advantage of the latest, Google-powered features while maintaining the added flexibility of EloView - making deployments and management a breeze.
Elo's Approach to Android
The Android mobile architecture is a smart choice for ensuring your rollout is inexpensive.
Fully Integrated
The I-Series is a fully integrated, Android-powered interactive system with the
performance needed to create the customer experience you want.
More Choice: Features to Match Your Needs
Get the freedom of choice. From color and size options to standard and value models, you can choose the configuration that matches your needs. If you need more memory and storage, ports for peripheral mounting and a webcam, then the standard models are the choice for you.
Configure with Elo Edge Connect
Built with versatility in mind, the Elo Edge Connect system offers a wide assortment of peripheral options. Whether for endless aisle, self-order or collaboration applications, you can seamlessly attach any combination of up to four peripherals to the edge of the touchscreen creating a bespoke solution. And, you can add or move them later as your needs change!
Power over Ethernet
Now you do not need to connect to a power adapter.
The Power-over-Ethernet (POE) module is an optional accessory you can pair with all I-Series 3.0 Models. All you need is a POE-capable network and to connect the POE Module to the I-Series.
In retail, where power drops can be expensive, running low voltage network cables allows for a lower cost solution. Or for AV applications (e.g., meeting rooms) - POE represents an easy-to -implement solution for conference room scheduler displays or AV control applications.
EloView
EloView allows you to deploy and securely manage your entire network of Android-powered interactive signage, point-of-sale systems and kiosk - from anywhere around the world. You can deploy content, manage settings and maintain the OS to reduce operating costs while increasing up-time and security.
The EloView architecture also allows you to leverage your content investments in mobile and web assets. Simply push your apps and responsive websites via the EloView portal. EloView's modular system is designed to integrate your business to enable smarter content distribution and device management abilities alongside your existing CMS platforms and MDM tools.
Virtual GPS via EloView
Often, applications depend upon the GPS location of individual devices to understand what content to display. The problem is a GPS chip does not work indoors and can be expensive to add to a device that spends its life fixed to a specific location.
With EloView, you can set the location (latitude/longitude) of the fixed device remotely, allowing the application to sync with the GPS coordinates. Now the application can run localized content because it knows where the unit is.
Display | |
Display diagonal | 39.6 cm (15.6") |
Display resolution | 1920 x 1080 pixels |
Touchscreen | Y |
Display type | TFT |
Display brightness | 300 cd/mý |
Touchscreen technology | Projected capacitive system |
Contrast ratio (typical) | 800:1 |
Viewing angle, horizontal | 170ø |
Viewing angle, vertical | 170ø |
Response time | 30 ms |
Effective viewing area | 344 x 194 mm |
Aspect ratio | 16:9 |
Display number of colours | 262144 colours |
Processor | |
Processor frequency | 2 GHz |
Processor manufacturer | Qualcomm |
Processor family | Qualcomm Snapdragon |
Processor model | APQ8053 |
Memory | |
Internal memory | 3 GB |
Internal memory type | DDR3L-SDRAM |
Storage | |
Total storage capacity | 32 GB |
Storage media type | SSD |
Storage media | SSD |
SSD capacity | 32 GB |
Features | |
Certification | UL/cUL, FCC, IC, CE, CB, KCC, NOM, BIS, ANATEL, BSMI |
Harmonized System (HS) code | 84715000 |
Multimedia | |
Built-in speaker(s) | Y |
Number of speakers | 2 |
Card reader integrated | Y |
Compatible memory cards | MicroSD (TransFlash) |
Network | |
Ethernet LAN | Y |
Ethernet LAN data rates | 1000 Mbit/s |
Bluetooth | Y |
Wi-Fi | Y |
Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
Ports & interfaces | |
Ethernet LAN (RJ-45) ports | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
Design | |
Chassis type | All-in-One |
Product colour | Black |
Software | |
Operating system installed | Android 8.1 |
Power | |
AC input voltage | 100-240 V |
AC input frequency | 50-60 Hz |
Power consumption (typical) | 13 W |
Operational conditions | |
Operating relative humidity (H-H) | 20 - 80% |
Operating temperature (T-T) | 0 - 40 øC |
Storage temperature (T-T) | -20 - 50 øC |
Storage relative humidity (H-H) | 5 - 95% |
Ergonomics | |
VESA mounting | Y |
Panel mounting interface | 75 x 75,100 x 100 mm |
Weight & dimensions | |
Width | 386.7 mm |
Depth | 248.2 mm |
Height | 28.3 mm |
Weight | 1.59 kg |
Packaging data | |
Quantity per pack | 1 pc(s) |
Package width | 470 mm |
Package depth | 300 mm |
Package height | 150 mm |
Package weight | 3.27 kg |
Packaging content | |
Cables included | AC |
Quick start guide | Y |
Warranty | |
Base Warranty | Non Non |
