Elopos Pack Black - 15.6in - i3 8100t - 8GB - 128GB SSD - Tpm 2.0 - Non Os
ITCurry #: M0134429 | Article #: E982670-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
The EloPOS Pack delivers a powerful enterprise-ready compute platform in a sleek, compact form factor. Backed by the security and infrastructure of a Windows-based system with Intel’s Q370 Chipset and the speed of the Intel’s 8th gen processors, the EloPOS Pack provides the power you need to run your business. With versatile connectivity options, plug in anything from Elo’s latest monitor via single cable USB-C to a legacy printer requiring a 12V powered-USB. The system provides flexibility to make upgrades as your business requirements change.
Designed for Versatility
From point-of-sale terminals and self-service kiosks to automation controls, the EloPOS Pack offers the connectivity and durability to thrive under the demands of continuous use.
Small Footprint
Purpose-built to accommodate compact spaces, the EloPOS Pack boasts a smaller footprint in both size and weight than other commercial-grade PCs.
Securely Mount
Easily secure the EloPOS Pack to any counter in a snap. Attach the mounting bracket to your desired location and simply clip it into place. And for added security, you can use the Kensington locks.
Connect It All
With 16 connection ports, you can connect all the peripherals you need. From cash drawers and printers to barcode scanners and payment devices — there is a port to connect it all.
Leverage the Best of Intel
Create a network with the security, performance and manageability you need for your business.
Windows or Linux. You Choose.
Whether you want Windows 10 or a no-OS model to run Linux, the enterprise-ready EloPOS Pack provides the freedom to adapt to your infrastructure. To get you up and running quicker, the no-OS models have been pretested with Linux SuSE, Ubuntu and Red Hat operating systems.
Get Peace of Mind With EloCare
EloCare provides service and support from the people who know your Elo products best. From extended warranties and on-site exchange to advance unit replacement and field services, the highly skilled Elo technical specialists will get you up and running.
Unite Your Digital Touchpoints
From your POS Terminals and self-service kiosks to your back-of-house systems, Elo has a solution for every touchpoint.
| Processor | |
| Processor frequency | 3.1 GHz |
| Processor family | Intel© CoreT i3 |
| Processor generation | 8th gen Intel© CoreT i3 |
| Processor model | i3-8100T |
| Processor cores | 4 |
| Processor cache | 6 MB |
| Processor threads | 4 |
| System bus rate | 8 GT/s |
| Motherboard chipset | Intel Q370 |
| Memory | |
| Internal memory | 8 GB |
| Internal memory type | DDR4-SDRAM |
| Maximum internal memory | 64 GB |
| Number of memory slots | 4 |
| Memory slots type | SO-DIMM |
| Memory clock speed | 2400 MHz |
| Storage | |
| Total storage capacity | 128 GB |
| Storage media type | SSD |
| Storage media | SSD |
| SSD capacity | 128 GB |
| SSD interface | Serial ATA III |
| SSD form factor | M.2 |
| Graphics | |
| Graphics card manufacturer | Intel |
| Graphics card | UHD Graphics 630 |
| Features | |
| Certification | UL/cUL, FCC, TUV, CE, CB, Mexico NOM, C-Tick/RCM, VCCI, Argentina S-Mark, CCC |
| Network | |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 1000 Mbit/s |
| Bluetooth | Yes |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| USB 2.0 ports quantity | 6 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 5 |
| Powered USB | Yes |
| HDMI ports quantity | 1 |
| Line-out | Yes |
| DC-in jack | Yes |
| Design | |
| Chassis type | Mini |
| Product colour | Black |
| Performance | |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Software | |
| Operating system installed | No |
| Power | |
| AC input voltage | 100-240 V |
| AC input frequency | 50-60 Hz |
| Power supply | 180 W |
| Power consumption (typical) | 48.87 W |
| Operational conditions | |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 40 øC |
| Storage temperature (T-T) | -20 - 60 øC |
| Storage relative humidity (H-H) | 0 - 95% |
| Ergonomics | |
| Mean time between failures (MTBF) | 50000 h |
| Weight & dimensions | |
| Width | 276 mm |
| Depth | 237.5 mm |
| Height | 37 mm |
| Weight | 2.6 kg |
| Packaging data | |
| Package width | 414 mm |
| Package depth | 346 mm |
| Package height | 169 mm |
| Package weight | 5 kg |
| Packaging content | |
| Cables included | AC, HDMI, USB, USB Type-C |
| Quick start guide | Yes |
| Power adapter included | Yes |
| Security | |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Sustainability | |
| Sustainability certificates | ENERGY STAR |
| Warranty | |
| Base Warranty | Non Non |
