Powered Subwoofer - T5s - Mono - Black
ITCurry #: Q9922436 | Article #: T5S-BLK-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Deep and Powerful Bass
Equipped with an 8-inch long-throw woofer, this subwoofer delivers deep, room-filling bass with frequency response down to 35Hz. A high-efficiency switching power supply and a closed-loop Class-D amplifier provide 70W RMS output for powerful and consistent performance.
Precision Digital Signal Processing
Featuring a high-performance analog front end and digital amplifier, the subwoofer ensures accurate audio conversion and amplification. The built-in digital signal processor (DSP) enables precise low-pass filtering and phase alignment for seamless integration with your speaker system.
Low Distortion Design
An 18mm MDF (medium-density fiberboard) enclosure minimizes resonance and distortion, resulting in tight, clean, and well-defined bass response.
Versatile Connectivity
Signal In and Signal Out ports ensure broad compatibility with desktop speakers, bookshelf systems, and home theater receivers.
- Method 1:
If your main speaker system includes a dedicated subwoofer output, connect it to the subwoofer's Signal In ports. Then connect the main speaker system directly to the audio source.
- Method 2:
If your speaker system does not have a subwoofer port, connect its input to the subwoofer's Signal Out ports. Then connect the Signal In ports of the subwoofer to the audio source.
Auto Standby Function
To conserve energy, the subwoofer automatically enters standby mode after 15 minutes of inactivity and wakes when audio playback resumes.
Stylish and Space-Saving Design
Wrapped in a wood grain vinyl finish with a low-profile grille, this subwoofer blends seamlessly into any room décor. The slim vertical cabinet design allows for flexible placement in tight or unconventional spaces.
| Subwoofer | |
| Subwoofer type | Active subwoofer |
| Subwoofer RMS power | 70 W |
| Subwoofer frequency range | 35 - 115 Hz |
| Subwoofer sensitivity | 85 dB |
| Subwoofer driver diameter (imperial) | 20.3 cm (8") |
| Input sensitivity | 150 mV |
| Low pass filter | Yes |
| Ports & interfaces | |
| Line-in | Yes |
| Line-out | Yes |
| Line inputs (RCA) | 1 |
| Features | |
| Product colour | Black |
| Material | MDF |
| On/off switch | Yes |
| Phase control | Yes |
| Power | |
| AC input voltage | 100 - 240 V |
| Weight & dimensions | |
| Subwoofer width | 39.9 cm |
| Subwoofer depth | 17 cm |
| Subwoofer height | 40 cm |
| Subwoofer weight | 10.4 kg |
| Packaging data | |
| Package type | Box |
| Warranty | |
| Base Warranty | Non Non |
