TRIPP LITE SmartRack 12U Standard-Depth 4-Post Open Frame Rack
ITCurry #: 57904489 | Article #: SR12UBEXPNDKD-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
The SmartRack 12U Standard-Depth 4-Post Open Frame Rack provides an economical rack-mount solution for small offices, retail locations and other secure IT locations with limited floor space where you need equipment to be organized and easy to access. It's ideal for mounting network switches, routers, patch panels, audio/video components and other EIA-standard 19-inch rack equipment up to 36 inches deep.
Constructed from heavy-duty steel with a durable black powder-coated finish, the SR12UBEXPNDKD has a maximum load capacity of 1000 lbs (453.6 kgs). Stashed away under a counter, on a workbench or in a corner, this rack saves precious space and allows you fast, easy access at your immediate workspace for organizing, installing and servicing equipment and cabling. The open design allows unobstructed airflow to help keep components cool and performing at their peak.
The self-squaring SR12UBEXPNDKD assembles using the included hardware. Built-in casters allow you to roll the rack into place. The vertical mounting rails have square, numbered holes and optional cable management hooks for securing equipment to the steel frame. Only user-supplied standard hand tools are required for setup. Toolless button holes accept 0U vertical installation of PDUs and cable managers.
| Features | |
| Rack capacity | 12U |
| Type | Freestanding rack |
| Product colour | Black |
| Material | Steel |
| Frame type | Open |
| Product design | 4-post |
| Certification | EIA-310-D, IEC 60297-3-100, RoHS |
| Warranty | |
| Base Warranty | Non Non |
| Weight & dimensions | |
| Size (imperial) | 48.3 cm (19") |
| Width | 517.4 mm |
| Depth | 912.9 mm |
| Height | 650.2 mm |
| Weight | 14.5 kg |
| Packaging data | |
| Wall mounting kit | Yes |
| Mounting kit | Yes |
| Manual | Yes |
| Package width | 213.6 mm |
| Package depth | 1088.6 mm |
| Package height | 98.8 mm |
| Package weight | 14.5 kg |
| Technical details | |
| Master (outer) case GTIN (EAN/UPC) | 10037332188479 |
| Logistics data | |
| Country of origin | China |
| Harmonized System (HS) code | 8517.79.0000 |
| Master (outer) case width | 929.9 mm |
| Master (outer) case length | 1120.1 mm |
| Master (outer) case height | 350 mm |
| Master (outer) case gross weight | 299.8 kg |
| Products per master (outer) case | 12 pc(s) |
