Eaton 9PX UPS, 2U - 1500VA/1350W, 5-15P input, Outputs: (8) 5-15R, 120V
ITCurry #: N4836389 | Article #: 9PX1500RT-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Business continuity for edge computing
When you need flexible protection for equipment in IT racks, network closets and mission-critical applications, look no further than the Eaton® 9PX UPS. Providing solutions that are reliable,
versatile, powerful and efficient, the 9PX integrates seamlessly
into just about any environment.
With double-conversion topology for constant power conditioning and ENERGY STAR qualification, the 9PX supports your overall goal of business continuity. It’s also built for scalable deployment and features a graphical LCD interface that enables local access to configurations and settings, history and diagnostics, energy consumption and load segment control.
Take a closer look
As a stand-alone, online double-conversion UPS, 9PX rack/ tower (RT) models can withstand harsh electrical environments for a variety of critical applications including IT, edge networks, industrial automation, healthcare and K-12. For edge networks and on-premise installations, Eaton focuses on integration within the virtualized environment. This means you can improve your infrastructure performance through virtual machine (VM) centric management, disaster recovery and validated integration capabilities.
The right 9PX solution may also include a software client that supports 2N (or N+1) UPS-protected graceful shutdown, a maintenance bypass to keep loads running during UPS replacement, or a rack to organize all of your IT equipment and cabling. It’s all about ensuring seamless integration and compatibility.
| Features | |
| UPS topology | Double-conversion (Online) |
| Output power capacity | 1.5 kVA |
| Output power | 1350 W |
| Waveform | Pure sine |
| Input operation voltage (min) | 100 V |
| Input operation voltage (max) | 125 V |
| Input frequency | 40/70 Hz |
| Output operation voltage (min) | 100 V |
| Output operation voltage (max) | 125 V |
| Output frequency | 50/60 Hz |
| Number of input phases | 1 |
| Efficiency | 90% |
| Output voltage Total Harmonic Distortion (THD) | 3% |
| Input current Total Harmonic Distortion (THD) | 3% |
| Noise level | 40 dB |
| Surge protection | Yes |
| Surge protection features | Network |
| Web-based management | Yes |
| Auto-restart | Yes |
| Ports & interfaces | |
| AC outlet types | NEMA 5-15R |
| Power plug | NEMA 5-15P |
| AC outlets quantity | 8 AC outlet(s) |
| USB port | Yes |
| USB 2.0 ports quantity | 1 |
| Serial interface | Yes |
| Serial interface type | RS-232 |
| RS-232 ports | 1 |
| Battery | |
| Battery technology | Sealed Lead Acid (VRLA) |
| Hot-swap battery | Yes |
| Automatic battery test | Yes |
| Cold start | Yes |
| Design | |
| Form factor | Rackmount/Tower |
| Rack capacity | 2U |
| Cable length | 2.44 m |
| Product colour | Black |
| Display type | LCD |
| LED indicators | Yes |
| Safety | LCD |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 øC |
| Storage temperature (T-T) | 0 - 35 øC |
| Operating relative humidity (H-H) | 0 - 96% |
| Storage relative humidity (H-H) | 0 - 96% |
| Operating altitude | 0 - 3000 m |
| Technical details | |
| Sustainability certificates | ENERGY STAR |
| Compliance certificates | RoHS |
| Weight & dimensions | |
| Width | 440 mm |
| Depth | 450 mm |
| Height | 86.5 mm |
| Weight | 19.3 kg |
| Package type | Box |
| Packaging data | |
| Rack mount kit | Yes |
| Bracket | Yes |
| Cables included | RS-232, USB cable |
| Management card included | No |
| Manual | Yes |
| Logistics data | |
| Harmonized System (HS) code | 85078000 |
| Other features | |
| Nominal output voltage | 120 V |
| Nominal input voltage | 120 V |
| Warranty | |
| Base Warranty | Non Non |
