Wireless Presentation System, 50m Dongle, up 16 to 1, Full HD, mobile screen sharing
ITCurry #: M9238930 | Article #: DS-55319-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Wirelessly transmits HDMI video and audio signals in Full HD over a distance of up to 50 m with an unobstructed view
- Wireless HDMI signal transmission up to 50 m (with unobstructed view)
- Supports up to 16x transmitters (sources) + 1x receiver (output device)
- Extend this set with up to 16 transmitter units (DS-55320)
- Switch to the desired transmitter quickly and easily at the press of a button in order to reproduce your content
- Share from a tablet/smartphone using the screen sync (iOS, iPadOS/Android) of your mobile device
- Supports Windows, macOS, iOS, iPadOS, Android
- Supports resolutions up to Full HD (1080p / 60 Hz)
- Easy operation and handling thanks to Plug & Play - Just plug in and get started
- Transmitter can be supplied with power via your device’s HDMI connection (> 500 mA required). To have a safe and stable operation, we recommend to use always the Micro USB cables for power supply of TX and RX.
With the Wireless Presentation System, you can wirelessly transmit HDMI video and audio signals in Full HD over a distance of up to 50 m with an unobstructed view. Operation and installation are super simple. Real Plug & Play - Just plug in and get started. With additional transmitters (DS-55320), the set can be extended to up to 16 transmitter units (total). Switch to the desired transmitter quickly and easily at the press of a button in order to reproduce your content. You can also share content directly from your mobile device (smartphone/table) using your device’s OS directly, no additional app required. Transmitter can be supplied with power via your device’s HDMI connection (> 500 mAh required). To have a safe and stable operation, we recommend to use always the Micro USB cables for power supply of TX and RX. Thanks to the compact design of the transmitter and receiver, installation is easy, quick and can be customized - the perfect solution for meeting and conference rooms.
| Features | |
| Type | AV transmitter & receiver |
| Maximum resolution | 1920 x 1080 pixels |
| Maximum transfer distance | 50 m |
| Audio system | stereo |
| LED indicators | Status |
| Security algorithms | 128-bit AES, WPA2 |
| HDCP | Yes |
| Material | ABS synthetics |
| HDCP version | 1.3 |
| Product colour | Black |
| Ports & interfaces | |
| Connectivity technology | Wireless |
| Wi-Fi | Yes |
| HDMI version | 1.4 |
| USB ports quantity | 1 |
| USB connector type | Micro-USB |
| Power | |
| Power consumption (typical) | 2.5 W |
| Power over Ethernet (PoE) | No |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 øC |
| Warranty | |
| Base Warranty | Non Non |
| Weight & dimensions | |
| Width | 32 mm |
| Depth | 83 mm |
| Height | 13 mm |
| Weight | 27 g |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
| Package width | 123 mm |
| Package depth | 123 mm |
| Package height | 120 mm |
| Package weight | 278 g |
| Packaging content | |
| Cables included | Micro-USB |
| Technical details | |
| Country of origin | China |
| Package volume | 756.45 cmü |
| Logistics data | |
| UK Trade Tariff code | 85176200 |
