Universal TV Ceiling Mount 37-70IN 560-910 mm black
ITCurry #: M9238512 | Article #: DA-90421-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Variable Ceiling Bracket for Flat and Curved Displays up to 70" / 50 kg, Height-Adjustable
- Universally suitable for displays from 37" to 70"
- Load capacity: 50 kg
- Suitable for flat and curved displays
- Variable telescopic height adjustment (35 cm)
- Adjustable mounting plinth - also suitable for sloping roofs with up to 60° inclination
- Freely selectable inclination from 0° to -25° for optimal viewing angle
- Cable management: Within the tube structure
- Quick-release monitor bracket (suspension device) - for easy installation
- Integrated level for perfect alignment
- Perfect for offices, conference rooms, restaurants/cafés, schools or hotels
The fully flexible Universal Ceiling Bracket from DIGITUS® leaves nothing to be desired. It is suitable for flat and curved displays with a screen diagonal from 37” to 70” and a weight of 50 kg. It can be optimally adjusted to different ceiling heights with telescopic height adjustment. The bracket can also be adapted to sloping roofs with an incline of up to 60° and can be swiveled by 360°. An optimal viewing angle is ensured by the variable inclination, which can be adjusted from 0 to -25° depending on the ceiling height and desired viewing angle. Installation is facilitated by the VESA bracket with quick release, as the display is clipped in to the corresponding mounts along with the installed VESA bracket. Clean cable management is provided within the telescopic structure. An integrated level helps with fine-tuning. The ceiling bracket can be used for VESA dimensions 200x200 to 600x400.
| Mounting | |
| Minimum screen size | 94 cm (37") |
| Maximum weight capacity | 50 kg |
| Maximum screen size | 177.8 cm (70") |
| Minimum VESA mount | 200 x 200 mm |
| Maximum VESA mount | 600 x 400 mm |
| Panel mounting interface | 200 x 200,300 x 300,400 x 200,400 x 400,600 x 400 |
| Number of displays supported | 1 |
| Mounting type | Ceiling |
| Ergonomics | |
| Height adjustment | Yes |
| Height adjustment range | 56 - 91 mm |
| Swivel angle | 360ø |
| Swivel angle range | -180 - 180ø |
| Angle of rotation | 3ø |
| Design | |
| Product colour | Black |
| Housing material | Steel |
| Technical details | |
| Country of origin | China |
| Weight & dimensions | |
| Width | 680 mm |
| Depth | 435 mm |
| Height | 1130 mm |
| Weight | 5.5 kg |
| Packaging data | |
| Package width | 780 mm |
| Logistics data | |
| Harmonized System (HS) code | 85299097 |
| Other features | |
| Mounting | Clamp |
| Warranty | |
| Base Warranty | Non Non |
