Product Information
High bandwidth without delays or signal loss
- QSFP+ 40G 10 m AOC cable
- 2.125-41.2 Gbps supported data rate
- Compatible brands: Allnet, CISCO, 3COM, D-LINK, Dell, Edimax, Etherwan, ENTERASYS, EXTREME, FINISAR, FORCE 10, Fortinet, HUAWEI, IBM, JUNIPER, LINKSYS, NETGEAR, NORTEL, RIVERSTONE, ZTE, ZYXEL
Active DIGITUS® 40G QSFP+ AOC cables are a high-performance, energy-saving, short-range connectivity solution that supports InfiniBand QDR/DDR/SDR,12.5G/10G/8G/8G/4G/4G/2G fibre channels, PCIe and SAS. They are compliant with the QSFP MSA and IEEE P802.3ba. Four full-duplex channels are used, with each channel capable of transferring data at rates of up to 11.3 Gbps, thus ensuring an aggregated rate of 45.2 Gbps. Active DIGITUS® 40G QSFP+ AOC cables provide increased port density and cost savings in the overall system.
Features | |
Cable length | 10 m |
Connector 1 | QSFP+ |
Connector 2 | QSFP+ |
Connector 1 gender | Male |
Connector 2 gender | Male |
Product colour | Aqua colour |
Full duplex | Yes |
Fiber mode structure | Multi-mode |
Wavelengths supported | 850 nm |
Ethernet interface type | 40 Gigabit Ethernet |
Data transfer rate | 41.2 Gbit/s |
Country of origin | China |
Operational conditions | |
Operating temperature (T-T) | 0 - 70 øC |
Packaging data | |
Quantity per pack | 1 pc(s) |
Package width | 260 mm |
Package depth | 260 mm |
Package volume | 1352 cmü |
Package weight | 100 g |
Logistics data | |
UK Trade Tariff code | 85176200 |
Harmonized System (HS) code | 85447000 |
Warranty | |
Base Warranty | Non Non |
