PoE-switch 4+1-Ports Ethernet Unmanaged 4-ports PoE,
ITCurry #: M9239112 | Article #: DN-95330-1-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Gigabit Ethernet PoE Switch 4-port PoE + 1-port uplink, 60W PoE budget
- Thanks to the PoE function, no additional power supply unit is required for the connected devices
- Minimize cabling for wireless APs, IP telephones, and any other PoE capable device
- Fanless design – perfect for office environments and meeting rooms
- Gigabit Ethernet Speed
- Additional Uplink Port
- PoE power budget: 60 Watts
- Supports PoE Power up to 32W for each PoE port
- Support One-Key CCTV functions
The DIGITUS 5-Port Gigabit Desktop Switch with four Power over Ethernet ports and one additional uplink Port, offers your network significant improvement in terms of performance and efficiency. Thanks to PoE support, you only need a single (network) cable for power and data transfer. This switch makes it much easier to connect devices such as access points, network cameras, and IP telephones, and requires far less cabling than alternatives. It also allows you to extend your network in places where there are no power supply cables or sockets available. The switch does not require any configuration and therefore guarantees quick and seamless integration into the network. Moreover, the switch’s fanless design ensures soundless operation, which makes this device the perfect solution for office environments and meeting rooms.
| Management features | |
| Switch type | Unmanaged |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 4 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Power connector | AC-in jack |
| Network | |
| Networking standards | IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x |
| 10G support | No |
| Auto MDI/MDI-X | Yes |
| MAC address auto-learning supported | Yes |
| MAC address auto-aging supported | Yes |
| VLAN support | No |
| Data transmission | |
| Switching capacity | 10 Gbit/s |
| MAC address table | 2000 entries |
| Jumbo frames support | Yes |
| Jumbo frames | 9000 |
| Design | |
| Rack mounting | No |
| Stackable | No |
| Product colour | Black |
| LED indicators | Yes |
| Performance | |
| Fanless | Yes |
| Power | |
| Power source | AC |
| Power supply included | Yes |
| Power consumption (max) | 3 W |
| Power protection features | Over voltage, Short circuit |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) ports quantity | 4 |
| Power over Ethernet (PoE) power per port | 15.4 W |
| Total Power over Ethernet (PoE) budget | 62 W |
| Other features | |
| Power supply | 65 W |
| Weight & dimensions | |
| Width | 76.7 mm |
| Depth | 140 mm |
| Height | 28 mm |
| Weight | 630 g |
| Packaging content | |
| Quick start guide | Yes |
| Packaging data | |
| Package width | 165 mm |
| Package depth | 60 mm |
| Package height | 192 mm |
| Package volume | 1900.8 cmü |
| Package weight | 722.5 g |
| Logistics data | |
| UK Trade Tariff code | 85176200 |
| Country of origin | China |
| Warranty | |
| Base Warranty | Non Non |
