installation cable - Cat 5e - F/UTP - AWG 24/1 - 305m - Grey
ITCurry #: M9234623 | Article #: DK-1521-V-305-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Future-oriented standards and high-end quality for your network.
- 1GBit Ethernet
- 100 Mhz transmission frequency
- PoE Power over Ethernet support
- CPR class Eca
The Digitus® Cat.5e F/UTP installation cable is characterized by the following cable construction 4x2x AWG23/1 and reaches a transmission frequency up to 100 MHz. The PVC cable jacket is conform to the CPR Euro class Eca. The cable is suitable for building structured cabling in the secondary and tertiary area. Compliant with the following standards ISO/IEC 11801, DIN EN 50173, DIN EN 50288-2-1.
Features | |
Product colour | Grey |
Cable length | 305 m |
Cable standard | Cat5e |
Cable shielding | F/UTP (FTP) |
Connector 1 | No |
Connector 2 | No |
Connector contacts plating | Gold |
Jacket material | Polyvinyl chloride (PVC) |
Conductor type | Solid |
Cable class | D |
Cabling technology | 10/100/1000Base-T(X) |
AWG wire size | 24/1 |
Certification | CPR class Eca |
Country of origin | China |
Packaging data | |
Package width | 400 mm |
Package depth | 210 mm |
Package weight | 13.5 kg |
Package volume | 35280 cmü |
Logistics data | |
Harmonized System (HS) code | 84733080 |
UK Trade Tariff code | 85444920 |
Warranty | |
Base Warranty | Non Non |
