Industrial 8-Port Fast Ethernet PoE Switch DIN rail, extended temp. range
ITCurry #: M9237884 | Article #: DN-650108
slide 1 of 1
Price:
73.26
Ex VAT
Shipping:
FREE Shipping on orders over 100€ Ex VAT.
Out of Stock. Contact Us!
Related products
slide 7 to 11 of 14
Product Information
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
| Network | |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x |
| 10G support | No |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX |
| Cable types supported | Cat3, Cat4, Cat5 |
| Full duplex | Yes |
| Flow control support | Yes |
| Auto MDI/MDI-X | Yes |
| MAC address auto-learning supported | Yes |
| MAC address auto-aging supported | Yes |
| Data transmission | |
| Switching capacity | 1.6 Gbit/s |
| MAC address table | 2000 entries |
| Store-and-forward | Yes |
| Design | |
| Product colour | Black, Blue |
| Housing material | Metal |
| LED indicators | Yes |
| Wall mountable | Yes |
| DIN rail mounting | Yes |
| Performance | |
| Mean time between failures (MTBF) | 300000 h |
| Power | |
| Power supply included | No |
| Redundant power supply (RPS) support | Yes |
| DC input voltage | 48 - 57 V |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) ports quantity | 8 |
| Power over Ethernet (PoE) power per port | 30 W |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 85 øC |
| Storage temperature (T-T) | -40 - 85 øC |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
| Weight & dimensions | |
| Width | 120 mm |
| Depth | 157 mm |
| Height | 48 mm |
| Packaging data | |
| User guide | Yes |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Warranty | |
| Base Warranty | Non Non |
