Gigabit switch - 8 Port RJ45 8 x 10/ 100/1000 Mbit/s
ITCurry #: M9239612 | Article #: DN-80066-1-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
The DN-80066-1 offers a simple, cost-effective and powerful way to bring your home or office network up to Gigabit speed.
- Gigabit speed: 8 adaptive 10/100/1000Mbps RJ45 ports offer ultra-fast network connections
- Simple installation: plug-and-play functionality, no configuration required
- High compatibility: Supports MDI/MDIX auto-flip for easy connection to various network devices
- Silent operation: fanless design for quiet and trouble-free operation
- Compact design: With dimensions of 140x67x26mm, it fits into any network environment
- Reliable performance: 16Gbps switching capacity and 11.9Mpps forwarding rate ensure smooth data traffic
- Low energy consumption: only 5W power consumption, ideal for continuous operation
- Stable connection: 4K MAC address table with auto-learning and auto-aging for efficient network management
- Safe operation: Supports earthing to protect against lightning strikes and overvoltage
- Wide range of applications: Ideal for home networks, small offices, hotels and campus networks
The DN-80066-1 SOHO network switch is the ideal solution for home networks and small offices. With 8 Gigabit ports, it offers fast and reliable connections for all your devices. Thanks to its simple plug-and-play installation and compact, fanless design, it requires little maintenance and fits perfectly into any network environment.
| Management features | |
| Switch type | Unmanaged |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity | 8 |
| Power connector | DC-in jack |
| Network | |
| Networking standards | IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
| 10G support | No |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Cable types supported | Cat3, Cat4, Cat5, Cat5e, Cat6 |
| MAC address auto-learning supported | Yes |
| MAC address auto-aging supported | Yes |
| VLAN support | No |
| Data transmission | |
| Switching capacity | 16 Gbit/s |
| Forwarding rate | 11.9 Mpps |
| MAC address table | 4000 entries |
| Store-and-forward | Yes |
| Design | |
| Rack mounting | No |
| Stackable | No |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Activity, Link, Power |
| Vandal-proof | No |
| Suitable for outdoor use | No |
| Performance | |
| Fanless | Yes |
| Power | |
| Power source | AC/DC |
| Power supply included | Yes |
| AC input voltage | 100 - 240 V |
| DC input voltage | 5 V |
| Input current | 1 A |
| Power consumption (typical) | 5 W |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | No |
| Other features | |
| Ethernet interface type | Gigabit Ethernet |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 øC |
| Storage temperature (T-T) | -40 - 70 øC |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Weight & dimensions | |
| Width | 67 mm |
| Depth | 140 mm |
| Height | 26 mm |
| Weight | 435 g |
| Packaging content | |
| Quick start guide | Yes |
| Packaging data | |
| Package width | 92 mm |
| Package depth | 149 mm |
| Package height | 69 mm |
| Package volume | 945.85 cmü |
| Package weight | 400 g |
| Logistics data | |
| Country of origin | China |
| Warranty | |
| Base Warranty | Non Non |
