Product Information
Minimization of the cabling costs for PoE-capable devices
- 24 10G ports with PoE+ support
- 370 watt performance with up to 30 watts per port
- Compatible with the IEEE802.3at standards
- Automatic surge protection
- Supports bandwidth up to 10Gbps
The DIGITUS® DN-95117 is an 24 port 10G PoE+ mid-span hub (PoE injector). It offers 24 input ports for data and 24 output ports which make data and PoE available. Each PoE-port supports connected devices in accordance with the IEEE802.3af and IEEE802.3at PoE standard with 15.4 watts and/or 30 watts, such as PoE access points, PoE IP-telephones or PoE IP cameras, for example. The switch makes available a maximum budget of 370 watts for all ports and maximum budget of 30 watts per port.
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Power connector | AC-in jack |
| Network | |
| Networking standards | IEEE 802.3af |
| 10G support | No |
| Full duplex | Yes |
| Auto MDI/MDI-X | Yes |
| Design | |
| Rack mounting | Yes |
| Form factor | 1U |
| Product colour | Grey |
| LED indicators | Power |
| On/off switch | Yes |
| Performance | |
| Plug and Play | Yes |
| Mean time between failures (MTBF) | 100000 h |
| Power | |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 4.5 A |
| Power consumption (max) | 270 W |
| Surge protection | Yes |
| Power protection features | Overload, Short circuit |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet plus (PoE+) ports quantity | 24 |
| Power over Ethernet (PoE) voltage range | 1.2 - 3.6 V |
| Power over Ethernet (PoE) power per port | 30 W |
| Total Power over Ethernet (PoE) budget | 370 W |
| Other features | |
| Ethernet interface type | Gigabit Ethernet |
| Operational conditions | |
| Operating temperature (T-T) | -10 - 45 øC |
| Storage temperature (T-T) | -20 - 70 øC |
| Operating relative humidity (H-H) | 0 - 90% |
| Storage relative humidity (H-H) | 0 - 95% |
| Weight & dimensions | |
| Width | 345 mm |
| Depth | 440 mm |
| Height | 45 mm |
| Weight | 4.39 kg |
| Packaging content | |
| Cables included | AC |
| Quick start guide | Yes |
| Packaging data | |
| Package type | Box |
| Package width | 405 mm |
| Package depth | 505 mm |
| Package height | 95 mm |
| Package volume | 19429.9 cmü |
| Package weight | 5.33 kg |
| Logistics data | |
| UK Trade Tariff code | 85176200 |
| Country of origin | China |
| Harmonized System (HS) code | 85176990 |
| Warranty | |
| Base Warranty | Non Non |
