24-port Fast Ethernet PoE Switch 2G Combo TP/SFP 390W
ITCurry #: M9237737 | Article #: DN-95343
slide 2 of 4
Price:
219.39
Ex VAT
Shipping:
FREE Shipping.
Out of Stock. Contact Us!
Related products
slide 7 to 11 of 14
Product Information
Integrated Power over Ethernet (PoE) solution for small and medium-sized networks
- 24 port 10/100Base-TX with PoE support
- 2-Port Combo Gigabit TP/SFP Uplink
- Maximum PoE power of 370 watts
- Supports one-click VLAN & CCTV mode
- Supports PD-ALIVE function
The DIGITUS® Fast Ethernet PoE switches are designed for medium to large network systems. The PoE function and the 19'' size make it easy to integrate into your network. The switches are a great choice to improve the performance and efficiency of your network.
| Management features | |
| Switch type | Unmanaged |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
| Combo SFP ports quantity | 2 |
| Network | |
| Networking standards | IEEE 802.3at |
| 10G support | No |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| VLAN support | Yes |
| Data transmission | |
| Switching capacity | 8.8 Gbit/s |
| Forwarding rate | 6.5 Mpps |
| MAC address table | 16384 entries |
| Packet forwarding rate (1 Gbps) | 1488095 pps |
| Packet forwarding rate (100 Mbps) | 148810 pps |
| Packet forwarding rate (10 Mbps) | 14881 pps |
| Design | |
| Rack mounting | Yes |
| Form factor | 1U |
| Product colour | Black, Silver |
| LED indicators | Activity, Link, PoE, Power |
| Number of fans | 2 fan(s) |
| Vandal-proof | No |
| Suitable for outdoor use | No |
| Performance | |
| Mean time between failures (MTBF) | 50000 h |
| Power | |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) ports quantity | 24 |
| Total Power over Ethernet (PoE) budget | 370 W |
| Other features | |
| Ethernet interface type | Fast Ethernet |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 øC |
| Storage temperature (T-T) | -40 - 70 øC |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Weight & dimensions | |
| Width | 440 mm |
| Depth | 207 mm |
| Height | 44 mm |
| Packaging data | |
| Package width | 493 mm |
| Package depth | 315 mm |
| Package volume | 11181.2 cmü |
| Package weight | 4.67 kg |
| Logistics data | |
| UK Trade Tariff code | 85176200 |
| Country of origin | China |
| Harmonized System (HS) code | 85176990 |
| Warranty | |
| Base Warranty | Non Non |
