1D 2D Barcode Scanner Desktop
ITCurry #: M9239170 | Article #: DA-81005-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Omni-directional bar code scanner with a scanning performance of up to 200 scans/s and elegant design for reliable use in checkout areas of pharmacies, supermarkets and other retail facilities
- Precise scanning of high-resolution 1D & 2D barcodes (barcodes / QR codes)
- 200 scans/s, bidirectional for reliable detection, successful code detection is confirmed by a light and audio signal.
- Reads barcodes on screens - ideal for payment via smartphone / QR code (e.g. e-wallet)
- Ideal for trade, logistics and commerce of all kinds
- Plug and Play - No additional drivers required
- Anti Inference: External light sources have no influence on the scan.
- The integrated infrared sensor automatically activates the scanner when a barcode is held in the scanning area.
- Compact design with swivel head, creates space in the checkout area
The 2D barcode scanner from DIGITUS® with high-resolution and motion-independent CMOS sensor allows fast and accurate scanning of static and non-static barcodes. Suitable for checkout areas in pharmacies, supermarkets and other retail facilities. Detects printed QR codes and QR codes displayed on screens (e.g. e-wallet). With 200 scans per sec., this bidirectional scanner delivers the best results. Suitable for one and omni-dimensional barcodes such as bar codes and QR codes. The scanner is also capable of reading QR codes from displays, ideal for scanning QR codes for mobile pay. Each scan is confirmed with visual and audible signals, supporting the most common types of encodings. Large scan angles further accelerate barcode recognition.
| Scanning | |
| Type | Barcode module bar code reader |
| Scanner type | 1D/2D |
| Sensor type | CMOS |
| Linear (1D) barcodes supported | China Post, Codabar, Code 11, Code 128, Code 32, Code 39, Code 93, EAN-13, EAN-8, GS1 DataBar, GS1 DataBar Omnidirectional, GS1 Databar Limited, GS1-128 (UCC/EAN-128), Industrial 2 of 5, Interleaved 2 of 5, MSI, Matrix 2 of 5, UPC-A, UPC-E |
| 2D (matrix & stacked) barcodes supported | Aztec Code, CodaBlockA, CodaBlockF, Composite Codes, Data Matrix, Dot Code A, Han Xin, MaxiCode, MicroPDF417, PDF417, QR Code |
| Read rate (max) | 200 reads/s |
| Maximum scan width | 10 cm |
| Ports & interfaces | |
| Connectivity technology | Wired |
| Standard interfaces | USB |
| Performance | |
| Built-in processor | Yes |
| Processor architecture | ARM Cortex-A7 |
| Product colour | Black |
| Country of origin | China |
| Power | |
| Power source type | USB |
| Weight & dimensions | |
| Width | 85 mm |
| Depth | 85 mm |
| Height | 140 mm |
| Weight | 250 g |
| Packaging data | |
| Cables included | USB |
| Package width | 120 mm |
| Package depth | 105 mm |
| Package height | 170 mm |
| Package weight | 433.333 g |
| Technical details | |
| Package volume | 2142 cmü |
| Logistics data | |
| UK Trade Tariff code | 84719000 |
| Warranty | |
| Base Warranty | Non Non |
