Optiplex 7020 - Sff - i5 12500 - 16GB Ram - 512GB SSD - Win 11 Pro

ITCurry #: 3314Y369 | Article #: 53DKX
Price:
563.67 Ex VAT
Shipping:
FREE Shipping.
Out of Stock. Contact Us!
Email us for assistance

Related products

slide 7 to 11 of 14

Product Information

Commercial desktop with DDR5 memory, 8 native USBs including 1 USB-C, 1 native DisplayPort, and 1 native HDMI.

Processor
Processor manufacturer Intel
Processor family Intel© CoreT i5
Processor generation 12th gen Intel© CoreT i5
Processor model i5-12500
Processor cores 6
Processor threads 12
Processor boost frequency 4.6 GHz
Performance cores 6
Performance-core Max Turbo Frequency 4.6 GHz
Performance-core base frequency 3 GHz
Processor cache 18 MB
Processor cache type Smart Cache
Number of processors installed 1
Processor base power 65 W
Maximum turbo power 117 W
Memory
Internal memory 16 GB
Maximum internal memory 64 GB
Internal memory type DDR5-SDRAM
Memory layout (slots x size) 1 x 16 GB
Memory slots 2x DIMM
Storage
Total storage capacity 512 GB
Storage media SSD
Optical drive type No
Number of storage drives installed 1
Total SSDs capacity 512 GB
Number of SSDs installed 1
SSD capacity 512 GB
SSD interface PCI Express
NVMe Yes
SSD form factor M.2
SSD performance class 25
M.2 SSD size 2230 (22 x 30 mm)
Graphics
Discrete graphics card No
On-board graphics card Yes
Discrete graphics card model Not available
On-board GPU manufacturer Intel
On-board graphics card family Intel© UHD Graphics
On-board graphics card model Intel UHD Graphics 770
Network
Ethernet LAN Yes
Ethernet LAN data rates 10,100,1000 Mbit/s
Cabling technology 10/100/1000Base-T(X)
Wi-Fi No
Ports & interfaces
USB 2.0 ports quantity 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity 1
HDMI ports quantity 1
HDMI version 1.4b
DisplayPorts quantity 1
DisplayPort version 1.4a
Combo headphone/mic port Yes
Number of SATA III connectors 1
Expansion slots
PCI Express x1 (Gen 3.x) slots 1
PCI Express x16 (Gen 3.x) slots 1
Design
Chassis type SFF
Placement supported Vertical
Cable lock slot Yes
Cable lock slot type Kensington
Product colour Black
Performance
Motherboard chipset Intel Q670
Audio chip Realtek ALC3204-CG
Audio system High Definition Audio
Trusted Platform Module (TPM) Yes
Trusted Platform Module (TPM) version 2.0
Product type PC
Software
Operating system installed Windows 11 Pro
Operating system architecture 64-bit
Operating system language German, Dutch, English, French, Italian
Trial software Activate Your Microsoft 365 For A 30 Day Trial
Power
Power supply 180 W
Power supply input voltage 90 - 264 V
Power supply input frequency 47/63 Hz
80 PLUS certification 80 PLUS Bronze
Operational conditions
Operating temperature (T-T) 10 - 35 øC
Storage temperature (T-T) -40 - 65 øC
Operating relative humidity (H-H) 20 - 80%
Storage relative humidity (H-H) 5 - 95%
Operating altitude -15.2 - 3048 m
Non-operating altitude -15.2 - 10668 m
Operating vibration 0.26 G
Non-operating vibration 1.37 G
Non-operating shock 105 G
Weight & dimensions
Width 92.6 mm
Depth 292.8 mm
Height 290 mm
Packaging content
Display included No
Mouse included on selected markets Dell Optical Mouse-MS116 - Black
Keyboard included on selected markets Dell Multimedia Keyboard-KB216 - UK (QWERTY) - Black
Cables included AC
Carbon footprint
Total carbon footprint (kg of CO2e) 160
Carbon emissions, manufacturing (kg of CO2e) 80
Carbon emissions, logistics (kg of CO2e) 11
Carbon emissions, energy usage (kg of CO2e) 64
Carbon emissions, end-of-life (kg of CO2e) 4
Total carbon emissions, w/o use phase (kg of CO2e) 96
PAIA version GaBi version 1, 2024
Warranty
Base Warranty Non Non
