Bto PowerEdge R540 - Intel Xeon Silver 4215 8 Core - 64GB RDIMM - 40 TB 3.5in Hot-plug Hard Drive - Windows Server 2019
ITCurry #: 3314V298 | Article #: BTOR54064GB40TB
slide 2 of 4
Key Specifications
- Form FactorRack (2U)
- ProcessorXeon® Eight-Core 4215 Scalable 2.50 GHz
- Memory64 GB
- View All Specs
Related products
slide 7 to 11 of 14
Product Information
Satisfy a variety of applications with the flexible PowerEdge R540. Its balanced combination of resources, expandability and affordability adapt to the changing demands of a modern data center. Optimize your application performance with one-button tuning. Scale for future requirements with up to 14 x 3.5 drives. Embedded diagnostics and SupportAssist help to maximize uptime without added effort, in a worry-free environment.
Our modern compute platforms are built to scale easily and take advantage of technologies that lift application performance. The PowerEdge R540 rack server combines affordably and versatility, so you can adapt to a variety of applications and meet future demands.
| Model Specs | |
| Model | PowerEdge R540 |
| Form/Chassis type | Rack (2U) |
| CPU | |
| Processor | Xeon Scalable |
| Processor Type | Intel® Xeon® |
| Processor Speed | Xeon® Eight-Core 4215 Scalable 2.50 GHz |
| Processor Std. | 1 |
| Memory | |
| Memory Type | DDR4-SDRAM |
| Memory Std. | 64 GB |
| Memory Max. | 512 GB |
| Memory Speed | 2667 MHz |
| Memory slots (total/available) | 16 |
| Drives / Storage | |
| Hard Disk Capacity | 40 TB |
| Hard Disk Controller | Dell PERC H730P+ |
| Hard Disk Interface | Hard drive interface : Serial ATA RAID support : Yes |
| Hard Disk HotSwap | Yes |
| Optical Drive | No |
| Interfaces | |
| Ports - Serial | 1 x Serial |
| Ports - USB | 1 x USB 2.0 - Type A (2 in front) 1 x USB 2.0 - micro-USB (1 in front) 2 x USB 3.0 - Type A (2 rear) |
| Ports - RJ-45 | 2 x LAN (Gigabit Ethernet) - RJ-45 |
| Ports - Monitor | 2 x VGA (1 front,1 rear) |
| Power Supply | |
| Voltage / Watt | 750 Watt |
| Power Supply HotSwap | Redundant power supply (RPS) support : No |
| General | |
| OS | Windows Server 2019 |
| Orientations allowed | Rack mounting : Yes |
| Dimensions | |
| Width | 48.2 cm (18.98 inches) |
| Depth | 68.1755 cm (26.84 inches) |
| Height | 8.68 cm (3.42 inches) |
| Certificates | |
| Green Compliant | Yes |
| Energy Star Certified | Yes |
Bto PowerEdge R540 - Intel Xeon Silver 4215 8 Core - 64GB RDIMM - 40 TB 3.5in Hot-plug Hard Drive - Windows Server 2019
6450.19
