MAGELLAN 3510hsi Sapphire Platter Def Conf 1d/2d Std Mount Euro Ps Rs232 Cbl
ITCurry #: 78558140 | Article #: M3511-010210-07104-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
IN-COUNTER HIGH PERFORMANCE BAR CODE READER
The Magellan 3510HSi series of scanners continue the Datalogic tradition of high performance imaging for the point-of-sale. With the same cables, mounts and exterior plastics as the Magellan 3550HSi, the 3510HSi scanner is easy to integrate into existing installations. The new electronics platform allows the M3510HSi to power from a single 5V USB connection, providing outstanding performance and easy connection to any POS system.
With a large field-of-view and the capabilities of imaging, the 3510HSi scanners provide outstanding performance on hard-to-read bar codes and seamless reading of a wide variety of bar codes. This Magellan scanner enables both high speed sweep and presentation scanning techniques ensuring maximum productivity and ergonomic ease, even with truncated (shortened), out-of-spec or poorly printed codes.
ENHANCING THE CUSTOMER EXPERIENCE
The optional Magellan Customer Service Scanner (CSS) enables retailers to easily engage their customers in mobile commerce programs, allowing them to scan bar codes from mobile phone screens or paper couponsm while the cashier continues to scan regular items in parallel, resulting in a significant reduction in total transaction time.
ENTERPRISE FEATURES
Remote management is supported for OPOS, JavaPOS, Toshiba Remote Management with IBM Systems Director® and Wavelink® Avalanche®. Additional capabilities are available with the Value Added Features included in every Magellan scanner.
| Scanning | |
| Type | Built-in bar code reader |
| Scanner type | 1D/2D |
| Linear (1D) barcodes supported | GS1 DataBar |
| 2D (matrix & stacked) barcodes supported | Aztec Code, Data Matrix, QR Code, WaterCode |
| Optical sensor resolution (W x H) | 1280 x 800 pixels |
| Tilt reading angle | 0 - 360ø |
| Pitch reading angle | 0 - 65ø |
| Yaw reading angle | -75 - 75ø |
| Ports & interfaces | |
| Connectivity technology | Wired |
| Standard interfaces | RS-232, USB |
| USB 2.0 ports quantity | 2 |
| Performance | |
| International Protection (IP) code | IP52 |
| Buzzer | Yes |
| Image formats supported | BMP, JPEG |
| Ambient lighting | Yes |
| Print contrast | 25% |
| Compatible memory cards | MicroSD (TransFlash) |
| Product colour | Black |
| Power | |
| Power source type | DC, USB |
| Power consumption (typical) | 2.1 W |
| Power consumption (standby) | 1.25 W |
| Input voltage | 100 - 240 V |
| Input frequency | 50 - 60 Hz |
| Weight & dimensions | |
| Width | 152 mm |
| Depth | 152 mm |
| Height | 87 mm |
| Weight | 980 g |
| Packaging data | |
| External power adapter | Yes |
| Cables included | RS-232 |
| Operational conditions | |
| Operating temperature (T-T) | 10 - 40 øC |
| Storage temperature (T-T) | -40 - 70 øC |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
| Technical details | |
| Sustainability certificates | RoHS |
| Compliance certificates | RoHS |
| Logistics data | |
| Harmonized System (HS) code | 84716070 |
| Warranty | |
| Base Warranty | Non Non |
