Hdmi 2.0 Active Optical Hybrid Cable 50m M/m
ITCurry #: M4192799 | Article #: CAC-1391-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
The Club 3D HDMI™ 2.0 Hybrid Active Optical Cable features both fiber and copper conductors, providing a lighter, more flexible cable construction, which makes it ideal for installation in narrow spaces and over longer distances. The perfect solution for conference rooms, classrooms, digital signage displays, and more.
This CAC-1391 features a built-in booster circuit that is self-powered through the HDMI ports, allowing you to connect your HDMI-enabled devices at a distance of up to 50 meters with no signal loss.
The cable is Halogen Free, and produced according to the International Electrochemical Commission's Restriction Use of Halogen (IEC 61249-2-21) directive.
This cable features unidirectional architecture, which requires that the cable is installed in the correct direction. Please refer to the source and display labels on the HDMI connectors, in order to ensure that the cable is connected properly.
| Features | |
| Cable length | 50 m |
| Connector 1 | HDMI Type A (Standard) |
| Connector 2 | HDMI Type A (Standard) |
| Connector 1 gender | Male |
| Connector 2 gender | Male |
| Connector 1 form factor | Straight |
| Connector 2 form factor | Straight |
| Product colour | Black, Bronze |
| HDMI version | 2.0b |
| Audio Return Channel (ARC) | Yes |
| HDCP | Yes |
| Data transfer rate | 18 Gbit/s |
| Maximum resolution | 7096 x 2160 pixels |
| Connector contacts plating | Gold |
| Cable material | Fiber optic/Copper |
| Plug and Play | Yes |
| Certification | ROHS, FCC and CE EMI |
| Quantity per pack | 1 pc(s) |
| Warranty | |
| Base Warranty | Non Non |
| Weight & dimensions | |
| Weight | 1.35 kg |
| Package width | 230 mm |
| Package depth | 100 mm |
| Package height | 230 mm |
| Package weight | 162 g |
| Package type | Box |
| Technical details | |
| Compliance certificates | RoHS |
| Logistics data | |
| Harmonized System (HS) code | 84733080 |
| Products per master (outer) case | 10 pc(s) |
