DisplayPort 1.2 To Hdmi 2.0 Uhd Active Adapter
ITCurry #: M4192772 | Article #: CAC-2070-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
The Club 3D CAC-2070 is an active HDMI™ 2.0 signal converter. The DisplayPort™ 1.2 to HDMI™2.0 4K 60Hz UHD Active Adapter is the easiest solution for connecting your DisplayPort™ 1.2 Game PC or Laptop to an HDMI™ enabled 4K UHD Television, monitor or Projector. The adapter is compliant to HDMI™ 2.0 specification allowing for 6Gbps TMDS through-put per channel. The interface in the adapter has three lanes for HDMI data, clock, HPD signal and power, offering a total TMDS throughput of 18Gbps.
Supports up to 4K UHD Resolution at 60Hz.
The DisplayPort™ 1.2 to HDMI™ 2.0 4K60Hz UHD Active Adapter supports UHD resolutions of up to 4K UHD 4096x 2160p @ 60Hz for a clear, sharp picture. The support for 60 frames per second provides exceptionally smooth video or gameplay. Use the adapter to play games, view video or browse the internet from your DisplayPort™ 1.2 enabled device in Ultra High Resolution. Supporting up to 8 channels of audio,the adapter provides Ultra High Definition digital audio and video. It is the ideal solution for anyone who wants to enjoy 4K UHD/60 gameplay but lacks a native HDMI™ 2.0 output in their system configuration.
| Ports & interfaces | |
| Connector 1 | Displayport 1.2 |
| Connector 2 | HDMI 2.0 |
| DisplayPort version | 1.2 |
| Cable length | 0.21 m |
| Performance | |
| Product colour | Black |
| Data transfer rate | 18 Gbit/s |
| USB required | No |
| Maximum resolution | 4096 x 2160 pixels |
| Maximum resolution (HDMI) | 4096 x 2160 pixels |
| Converter type | Active video converter |
| Maximum refresh rate | 60 Hz |
| Plug and Play | Yes |
| Compatible operating systems | Windows 10, 8.1 MAC OSx |
| Certificates | |
| Compliance certificates | RoHS |
| Certification | ROHS, FCC and CE EMI |
| Weight & dimensions | |
| Width | 44 mm |
| Depth | 14, 210 |
| Weight | 32 g |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Packaging data | |
| Package width | 160 mm |
| Package depth | 18 mm |
| Package height | 240 mm |
| Package weight | 6 g |
| Package type | Polybag |
| Plastic packaging weight | 11 g |
| Total plastic packaging weight | 55 g |
| Technical details | |
| Cable colour | Black |
| Host interface | Displayport 1.2 |
| Logistics data | |
| Country of origin | China |
| Products per master (outer) case | 10 pc(s) |
| Harmonized System (HS) code | 8544 4290 |
| Warranty | |
| Base Warranty | Non Non |
