Ie4010 4x 1g Sfp 24 10/100/1000 Ge Poe Lan Base
ITCurry #: 0918U367 | Article #: IE-4010-4S24P=-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Cisco® Industrial Ethernet (IE) 4010 Series Switches with 28 Gigabit Ethernet interfaces are high-performance ruggedized Layer2/3 switches with high-density Power-over-Ethernet (PoE) capabilities, making them an ideal choice for use as access switches in industrial environments. The 4010 delivers comprehensive Cisco IOS® Software security features and high-availability ring protocols. The switch is ideal for outdoor enclosures or harsh environments while adhering to overall IT network design, compliance, and performance requirements.
The 4010 has a comprehensive software feature set, developed from manufacturing, utility, and enterprise switching products making it excellent for extended temperature range locations, such as smart buildings, utility, process control, intelligent transportation systems (ITS), and city surveillance programs. The 4010 complements the existing Cisco IE 2000, IE 2000U, IE 3000, IE 3010, IE 4000, and IE 5000 Series Switching families, as well as the Cisco CGS 2520 Switch.
The 4010 supports a GUI-based web user Interface, and Express Setup for the switch provides easy out-of-box configuration to deliver advanced security, data, video, and voice services over industrial networks.
| Management features | |
| Switch type | Managed |
| Switch layer | L2/L3 |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
| ARP inspection | Yes |
| System event log | Yes |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| SFP module slots quantity | 4 |
| Fiber optic connector | SFP |
| Console port | RJ-45 |
| USB 2.0 ports quantity | 1 |
| Compatible memory cards | SD |
| Network | |
| Networking standards | IEEE 802.3, IEEE 802.3af, IEEE 802.3at |
| 10G support | No |
| Full duplex | Yes |
| Link aggregation | Yes |
| Broadcast storm control | Yes |
| Rate limiting | Yes |
| Spanning tree protocol | Yes |
| VLAN support | Yes |
| Virtual LAN features | Private VLAN |
| Data transmission | |
| Switching capacity | 56 Gbit/s |
| Throughput | 41.67 Mpps |
| MAC address table | 16000 entries |
| Number of queues | 4 |
| Security | |
| DHCP features | DHCP server |
| IGMP snooping | Yes |
| Security algorithms | 802.1x RADIUS, FIPS 140-2, SNMP, SSH |
| BPDU filtering/protection | Yes |
| Authentication | Guest VLAN |
| Multicast features | |
| Multicast support | Yes |
| Protocols | |
| Supported network protocols | IPv4, IPv6, VTPv2, NTP, UDLD, CDP, LLDP, HTTP |
| Design | |
| Rack mounting | Yes |
| Form factor | 1U |
| Product colour | Black |
| Certification | RoHS, TAA, CE |
| Performance | |
| Memory type | DRAM |
| Internal memory | 1000 MB |
| Flash memory | 128 MB |
| Mean time between failures (MTBF) | 429620 h |
| Power | |
| Power consumption (max) | 90 W |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet plus (PoE+) ports quantity | 24 |
| Warranty | |
| Base Warranty | Non Non |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 75 øC |
| Storage temperature (T-T) | -40 - 85 øC |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating altitude | 0 - 4206.24 m |
| Non-operating altitude | 0 - 4572 m |
| Weight & dimensions | |
| Weight | 5.46 kg |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
