Product Information
The Cisco Secure Firewall with the Firepower 1140 appliance and FTD software provides robust, proven Layer 3 and 4 security control as well as Layer 7 application visibility and control and is ready for advanced threat defence (separately licensed). Ideal for small and medium-sized offices, it includes support for advanced remote access VPN termination, plus BGP and OSPF routing functions.
Data transmission | |
Firewall throughput | 2.2 Gbit/s |
IPSec VPN throughput | 1.2 Gbit/s |
Maximum firewall connections | 400000 |
Maximum firewall connections per second | 100000 |
Performance | |
Built-in processor | Yes |
Processor family | Intel |
Processor cores | 16 |
Network | |
Wi-Fi | No |
Security | |
Stateful Packet Inspection (SPI) | Yes |
Protocols | |
Supported network protocols | SMTP |
Management features | |
URL filtering | Yes |
Ports & interfaces | |
Connectivity technology | Wired |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 8 |
Console port | RJ-45 |
Number of console ports | 1 |
SFP module slots quantity | 4 |
Storage | |
Storage media type | SSD |
SSD capacity | 200 GB |
Design | |
Rack mounting | Yes |
Form factor | 1U |
Power | |
AC input voltage | 100-240 V |
AC input frequency | 50 - 60 Hz |
Input current | 2 A |
Power consumption (max) | 100 W |
Logistics data | |
Country of origin | Mexico |
Quantity per pack | 1 pc(s) |
Harmonized System (HS) code | 85176990 |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 øC |
Storage temperature (T-T) | -25 - 70 øC |
Operating relative humidity (H-H) | 10 - 90% |
Storage relative humidity (H-H) | 10 - 90% |
Operating altitude | 0 - 3000 m |
Weight & dimensions | |
Width | 268.7 mm |
Depth | 436.9 mm |
Height | 43.7 mm |
Packaging data | |
Package width | 990.6 mm |
Package height | 457.2 mm |
Package depth | 1409.7 mm |
Package weight | 5.78 kg |
Other features | |
Firewall throughput | 2200 Mbit/s |
Warranty | |
Base Warranty | Non Non |
