Product Information
The Cisco Aironet AIR-ANT2568VG-N= Dual-Band Omnidirectional Wi-Fi Antenna is designed with improved coverage and performance in mind. This FCC-approved omnidirectional antenna provides a 360-degree radiation pattern and is intended for deployment when coverage in all directions from the antenna is required.
| Performance | |
| Frequency band | 2400 - 2483, 5150 - 5925 GHz |
| Antenna gain (2.4 GHz) | 6 dBi |
| Antenna gain (5 GHz) | 8 dBi |
| Impedance | 50 O |
| Antenna gain level (max) | 8 dBi |
| Features | |
| Antenna type | Omni-directional antenna |
| Antenna connector type | N-type |
| Polarization | Vertical polarization |
| International Protection (IP) code | IP67 |
| Country of origin | China |
| Operational conditions | |
| Operating temperature (T-T) | -30 - 70 øC |
| Storage temperature (T-T) | -40 - 85 øC |
| Weight & dimensions | |
| Height | 377 mm |
| Diameter | 3.81 cm |
| Weight | 204.1 g |
| Package width | 152.4 mm |
| Package depth | 482.6 mm |
| Package height | 50.8 mm |
| Package weight | 362.81 g |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Packaging content | AIR-ANT2568VG-N Antenna |
| Logistics data | |
| Harmonized System (HS) code | 85177100 |
| Warranty | |
| Base Warranty | Non Non |
