Catalyst 9800-40 Wireless Controller
ITCurry #: 0918V595 | Article #: C9800-40-K9-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Built from the ground-up for the Intent-based networking and Cisco DNA, Cisco Catalyst 9800 Series Wireless Controllers are Cisco IOS® XE based and integrate the RF excellence of Cisco Aironet® access points creating the best-in-class wireless experience for your evolving and growing organization. The Cisco Catalyst 9800 Series Wireless Controllers are built on an open and programmable architecture with built-in security, streaming telemetry and rich analytics.
The Cisco Catalyst 9800 Series Wireless Controllers are built on the three pillars of network excellence— always on, secure, and deployed anywhere— which strengthen the network by providing the best wireless experience without compromise, while saving time and money.
The Cisco® Catalyst® 9800-40 is a fixed wireless controller with seamless software updates for midsize and large enterprises.
The Cisco Catalyst 9800-40 is feature rich and enterprise ready to power your business-critical operations and transform end-customer experiences:
- High availability and seamless software updates, enabled by hot and cold patching, keep your clients and services always on during planned and unplanned events.
- Secure air, devices, and users with the Cisco Catalyst 9800-40. Wireless infrastructure becomes the strongest first line of defense with Cisco Encrypted Traffic Analytics (ETA) and Software-Defined Access (SD-Access). The controller comes with built-in security: secure boot, runtime defenses, image signing, integrity verification, and hardware authenticity.
- Built on a modular operating system, the 9800-40 features open and programmable APIs that enable automation of day-0 to day-N network operations. Model-driven streaming telemetry provides deep insights into the health of your network and clients.
| Design | |
| Product colour | Grey |
| Rack capacity | 1U |
| Performance | |
| Control display unit | No |
| Network | |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Forwarding rate | 40000 Mpps |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11h, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11u, IEEE 802.11w |
| Switching capacity | 40 Gbit/s |
| Security | |
| Access Control List (ACL) | Yes |
| VLAN support | Yes |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| WAN connection | Ethernet (RJ-45) |
| Management features | |
| Quality of Service (QoS) support | Yes |
| Power | |
| Input voltage | 264 V |
| Input frequency | 47 - 63 Hz |
| Heat dissipation | 1300 BTU/h |
| Weight & dimensions | |
| Width | 439.4 mm |
| Depth | 495.3 mm |
| Height | 43.7 mm |
| Weight | 10.3 kg |
| Operational conditions | |
| Operating temperature (T-T) | 5 - 40 øC |
| Storage temperature (T-T) | -40 - 65 øC |
| Operating relative humidity (H-H) | 5 - 85% |
| Storage relative humidity (H-H) | 5 - 90% |
| Operating altitude | 0 - 3000 m |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Warranty | |
| Base Warranty | Non Non |
