Catalyst 9163e Ap(w6e Tri-band 2x2 Outdoor) W/reg-e
ITCurry #: 0918Y459 | Article #: CW9163E-E-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
The Cisco Catalyst™ 9163E Wi-Fi 6E access point is designed with a weatherized and robust enclosure, helping ensure uninterrupted wireless access in even the most challenging outdoor environments. As part of the Cisco Catalyst 9160 Series, the 9163E offers the flexibility to choose between on-premises and cloud management with the ability to change at any time, giving you the freedom to network your way.
This next-generation access point is specifically designed to extend your Wi-Fi 6E network outdoors, catering to a wide range of use cases from campus environments and municipal Wi-Fi to stadiums, airport hangars, and everything in between. This access point is not only reliable and secure but also highly flexible and intelligent, adapting to your network requirements seamlessly.
| Features | |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| 6 GHz | Yes |
| Cabling technology | 10/100/1000/2500Base-T |
| MIMO | Yes |
| MIMO type | Multi User MIMO |
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
| VLAN support | Yes |
| Virtual LAN features | Tagged VLAN |
| Maximal-Ratio Combining (MRC) | Yes |
| Quality of Service (QoS) support | Yes |
| Security | |
| Security algorithms | EAP-TLS, EAP-TTLS, WPA2-Enterprise, WPA2-PSK, WPA3-Personal |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| Power | |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) type supported | PoE+ |
| Power consumption (typical) | 25 W |
| Design | |
| Placement | Pole, Wall |
| Product colour | Grey |
| Antenna | |
| Antenna type | External |
| Antennas quantity | 4 |
| Antenna connector type | N-type |
| Performance | |
| Flash memory | 1024 MB |
| Internal memory | 2048 MB |
| Weight & dimensions | |
| Width | 245 mm |
| Depth | 245 mm |
| Height | 63.5 mm |
| Weight | 1.5 kg |
| Operational conditions | |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | -40 - 65 øC |
| Storage temperature (T-T) | -30 - 70 øC |
| Operating altitude | 0 - 3000 m |
| Warranty | |
| Base Warranty | Non Non |
