Catalyst 8300-1n1s-4t2x - Router - 10 Gige - Rack-mountable
ITCurry #: 0918V117 | Article #: C8300-1N1S-4T2X-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Cisco Catalyst 8300 Series Edge Platforms (Catalyst 8300) with Cisco IOS XE SD-WAN Software deliver Cisco’s secure, cloud-scale SD-WAN solution for the branch. The Catalyst 8300 Series is purpose-built for high performance and integrated SD-WAN Services along with flexibility to deliver security and networking services together from the cloud or on premises. It provides higher WAN port density and a redundant power supply capability. The Catalyst 8300 Series Edge Platforms have a wide variety of interface options to choose from—ranging from lower and higher module density with backward compatibility to a variety of existing WAN, LAN, voice, and compute modules. Powered by Cisco IOS XE, fully programmable software architecture, and API support, these platforms can facilitate automation at scale to achieve zero-touch IT capability while migrating workloads to the cloud. Catalyst 8300 Series Edge Platforms also come with Trustworthy Solutions 2.0 infrastructure that secures the platforms against threats and vulnerabilities with integrity verification and remediation of threats.
The Catalyst 8300 Series Edge Platforms are well suited for medium-sized and large enterprise branch offices for high WAN IPSec performance with integrated SD-WAN services.
| WAN connection | |
| Ethernet WAN | Yes |
| DSL WAN | Yes |
| SIM card slot | No |
| 3G/4G USB modem compatibility | No |
| SFP WAN | Yes |
| Network | |
| Networking standards | IEEE 802.1Q, IEEE 802.1ag, IEEE 802.3ah |
| Ethernet interface type | 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet |
| Ethernet LAN data rates | 100,1000,10000 Mbit/s |
| Throughput | 15.8 Gbit/s |
| Management features | |
| Web-based management | Yes |
| Quality of Service (QoS) support | Yes |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 4 |
| SFP+ module slots quantity | 2 |
| USB ports quantity | 2 |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| Protocols | |
| Switching protocols | MPLS |
| Routing protocols | BGP, EIGRP, HSRP, IP, IS-IS, LISP, MPLS, OSPF, OSPFv3, RIP, RIP-2, VRRP |
| DHCP client | Yes |
| DHCP server | Yes |
| IPv4 & IPv6 features | IPv4/IPv6 access-control list (ACL) |
| Security | |
| Security algorithms | 256-bit AES, 2048-bit RSA, SHA-1, SHA-2 |
| Firewall | Yes |
| Authentication method | AAA, RSA (2048 bit), ESP-256-CBC, HMAC-SHA1, ECDSA (256/384 bit) |
| URL filtering | Yes |
| Access Control List (ACL) | Yes |
| Network address translation (NAT) | Yes |
| Features | |
| Processor manufacturer | Intel |
| Storage media | SSD |
| Internal storage capacity | 16 GB |
| Flash memory | 8192 MB |
| Internal memory | 8192 MB |
| Internal memory type | DDR4 |
| Maximum memory card size | 32 GB |
| Mean time between failures (MTBF) | 536060 h |
| Design | |
| Product colour | Grey |
| Rack mounting | Yes |
| Rack capacity | 1U |
| LED indicators | Yes |
| Power | |
| Power source type | AC |
| AC input voltage | 85 - 264 V |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 øC |
| Storage temperature (T-T) | -40 - 70 øC |
| Operating relative humidity (H-H) | 5 - 85% |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating altitude | 0 - 3050 m |
| Weight & dimensions | |
| Width | 444.5 mm |
| Depth | 412.8 mm |
| Height | 43.9 mm |
| Warranty | |
| Base Warranty | Non Non |
