Catalyst 2960-x 24 Gige 4 X 1g Sfp Lan Base - Refu

ITCurry #: 0918U146 | Article #: WS-C2960X24TS-L-RF
Flash Sale
Price:
917.01 Inc VAT Ex VAT
Shipping:
Out of Stock. Contact Us!
Email us for assistance
Key Specifications
  • Screen
    Memory
    Weight
    Processor
    Hard Disk
    SSD
    Screen
    Resolution
    Connectivity
    Memory
    Case
    OS
    Screen
    Type
    Speed Black
    Speed Colour
    Model
    Processor Speed
    Form Factor
    Internal / External
    Port Count
    Uplink / media
    Mounting
  • View All Specs

Bundles

Inc VAT Ex VAT
Out of Stock. Contact Us!
Inc VAT Ex VAT
Out of Stock. Contact Us!

Inc VAT Ex VAT
Out of Stock. Contact Us!

Inc VAT Ex VAT
Out of Stock. Contact Us!

Related products

Product Information

Management features
Switch type Managed
Switch layer L2/L3
Quality of Service (QoS) support Yes
Web-based management Yes
ARP inspection Yes
System event log Yes
MIB support BRIDGE-MIB, CISCO-CDP-MIB, CISCO-CLUSTER-MIB, CISCO-CONFIG-MAN-MIB, CISCO-ENTITY-FRU-CONTROL-MIB, CISCO-ENVMON-MIB, CISCO-FLASH-MIB, CISCO-FTP-CLIENT-MIB, CISCO-HSRP-MIB, CISCO-HSRP-EXT-MIB, CISCO-IGMP-FILTER-MIB, CISCO-IMAGE-MIB, CISCO-IP-STAT-MIB, CISCO-L2L3-INTERFACE-CONFIG-MIB, CISCO-MAC-NOTIFICATION-MIB, CISCO-MEMORY-POOL-MIB, CISCO-PAGP-MIB, CISCO-PING-MIB, CISCO-PROCESS-MIB, CISCO-RTTMON-MIB, CISCO-STP-EXTENSIONS-MIB, CISCO-SYSLOG-MIB, CISCO-TCP-MIB, CISCO-VLAN-IFTABLE-RELATIONSHIP-MIB, CISCO-VLAN-MEMBERSHIP-MIB, CISCO-VTP-MIB, ENTITY-MIB, ETHERLIKE-MIB, IF-MIB, IGMP-MIB, IPMROUTE-MIB, OLD-CISCO-CHASSIS-MIB, OLD-CISCO-FLASH-MIB, OLD-CISCO-INTERFACES-MIB, OLD-CISCO-IP-MIB, OLD-CISCO-SYS-MIB, OLD-CISCO-TCP-MIB, OLD-CISCO-TS-MIB, OSPF-MIB (RFC 1253), PIM-MIB, RFC1213-MIB, RFC1253-MIB, RMON-MIB, RMON2-MIB, SNMP-FRAMEWORK-MIB, SNMP-MPD-MIB, SNMP-NOTIFICATION-MIB, SNMP-TARGET-MIB, SNMPv2-MIB, TCP-MIB, UDP-MIB
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity 24
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity 24
SFP module slots quantity 4
Console port RJ-45
USB 2.0 ports quantity 2
Power connector AC-in jack
Network
Networking standards IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support Yes
Copper ethernet cabling technology 10BASE-T, 100BASE-T, 1000BASE-T
Cable types supported Cat5e
Full duplex Yes
IP routing Yes
Link aggregation Yes
Broadcast storm control Yes
Rate limiting Yes
Auto MDI/MDI-X Yes
Spanning tree protocol Yes
Ethernet LAN data rates 10,100,1000 Mbit/s
Auto-negotiation Yes
VLAN support Yes
Number of VLANs 1023
Data transmission
Switching capacity 216 Gbit/s
Throughput 71.4 Mpps
MAC address table 16000 entries
Number of queues 8
Number of static routes 1000
Jumbo frames support Yes
Jumbo frames 9216
Security
DHCP features DHCP server
Access Control List (ACL) Yes
Access Control List (ACL) rules 3
IGMP snooping Yes
Security algorithms SNMP, SSH
Static port security Yes
SSH/SSL support Yes
BPDU filtering/protection Yes
IP-MAC-Port binding Yes
Authentication MAC-based authentication, Port-based authentication
Multicast features
Multicast support Yes
Number of multicast groups filtered 1000
Protocols
Management protocols SNMP 1, RMON 1, RMON 2, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, SSH, CLI
Switching protocols UDP, TCP, RADIUS/TACACS+
Routing protocols HSRP, IP, RIP-1, RIP-2, RIPng
Design
Rack mounting Yes
Stackable Yes
Form factor 1U
Product colour Black
LED indicators Yes
Certification 47CFR Part 15 (CFR 47), AS/NZS CISPR22, CISPR22, EN55022, ICES003, VCCI, EN61000-3-2, EN61000-3-3, KN22, CNS13438
Performance
Physical stacking (units) 8
Built-in processor Yes
Processor model AppliedMicro APM8639
Processor frequency 600 MHz
Memory type DRAM
Internal memory 512 MB
Flash memory 128 MB
Noise level 48 dB
Mean time between failures (MTBF) 564910 h
Power
Power supply included Yes
Redundant power supply (RPS) support Yes
Number of power supply units 1
AC input voltage 120 - 230 V
AC input frequency 50 - 60 Hz
Power consumption (typical) 36.9 W
Power over Ethernet (PoE)
Power over Ethernet (PoE) No
Operational conditions
Operating temperature (T-T) -5 - 40 øC
Storage temperature (T-T) -25 - 70 øC
Operating relative humidity (H-H) 10 - 95%
Storage relative humidity (H-H) 10 - 95%
Operating altitude 0 - 3000 m
Non-operating altitude 0 - 4000 m
Weight & dimensions
Width 431.8 mm
Depth 279 mm
Height 25.4 mm
Weight 4 kg
Packaging data
Cables included AC
User guide Yes
Manual Yes
Sustainability
Sustainability certificates ENERGY STAR
Warranty
Base Warranty Non Non
